1/4" Malleable Guy Clip Allied H-885

• For 1/4" Strand
• A heavy duty means of securing down guys and wire rope.

• Comprised of a Malleable Iron base, “U” bolt, and two hex nuts.

• All components are hot dip galvanized to meet ASTM Specification A153.

2 Bolt Guy Clamp 3-3/8Lng " with 1/2" Bolts J1030/ALL 5058

• Used to form guy loops that attach to anchor rods or dead-ends.
• Parallel grooves accept strand without marring.
• Plate halves align evenly for ease of installation.
• Plate length is 3-3/8" and plate width is 1-9/16".
• Strand sizes accommodated are 3/16" (2.2 M) -3/8" (10 M).
• Comprised of two plates and two 1/2" X 1-5/8" Carriage Bolts with Regular Square Nuts.
• Hot dip galvanized to meet ASTM Specification A153.
• H-J1030-ALL-5058
• This is not a suspension clamp

3 Bolt Clamp Marriage Guy Clamp 4"with 1/2" Bolts, 3/16" - 7/16" Strand Range H-J929

MSI H-J929 3 Bolt Marriage Guy Clamp 4"with 1/2" Bolts, 3/16" - 7/16" Strand Range
3 Bolt Clamp Marriage Guy Clamp
Specifications/Features:

• Number of Bolts: 3
• Clamp Bolt Diameter: 1/2"
• Clamp Length: 4"
• Clamp Width: 1-9/16"
• Strand Diameter: 3/16" - 7/16"
• Rolled from carbon steel with straight parallel groove that will not damage strand
• The clamping bolts have special shoulders to prevent turning when the nuts are tightening
• Construct of high quality steel, hot-dip galvanized

Not to be used as a suspension clamp

3 Bolt Clamp Marriage Guy Clamp 6" with 1/2" Bolts, 3/16" - 7/16" Strand Range H-J930

3 Bolt Clamp Marriage Guy Clamp 6" with 5/8" Bolts, 5/16" - 1/2" Strand Range H-J931

MSI H-J931 3 Bolt Marriage Guy Clamp 6", 5/16" - 1/2" Strand Range
3 Bolt Clamp Marriage Guy Clamp

Specifications/Features:

• Number of Bolts: 3
• Clamp Bolt Diameter: 5/8"
• Clamp Length: 6"
• Clamp Width: 1-21/32"
• Strand Diameter: 5/16" - 1/2"
• Rolled from carbon steel with straight parallel groove that will not damage strand
• The clamping bolts have special shoulders to prevent turning when the nuts are tightening
• Construct of high quality steel, hot-dip galvanized

Not to be used as a suspension clamp. Can also be used with the SideWalk Guy Clamp End J0522

3 Bolt Suspension Clamp for Figure 8 Cable (.109-.134") Allied Bolt 7026

• Used to secure figure 8 cable to telephone poles. Bitch clamp

• Each Suspension Clamp is comprised of two aluminum plates, two 1/2" carriage bolts, and two square nuts.

• The plates are extruded and stamped from 6063-T6 Aluminum.

• Center hole accommodates 5/8" bolts.

• Figure 8 Three-Bolt Suspension Clamps are 6" long.

• Carriage bolt and nuts are formed from Grade 2 Steel.

• Carriage bolts and square nuts are hot dip galvanized to meet ASTM Specification A153, Class C.

3-Bolt Suspension Clamp for Figure 8 Cable (.148-.250") Allied Bolt 7027

• Used to secure figure 8 cable to telephone poles.
• Each Suspension Clamp is comprised of two aluminum plates, two 1/2" carriage bolts, and two square nuts.
• The plates are extruded and stamped from 6063-T6 Aluminum.
• Center hole accommodates 5/8" bolts.
• Figure 8 Three-Bolt Suspension Clamps are 6" long.
• Carriage bolt and nuts are formed from Grade 2 Steel.
• Carriage bolts and square nuts are hot dip galvanized to meet ASTM Specification A153.

3/8" Malleable Guy-Clip Allied H-887

• for 3/8 strand
• A heavy duty means of securing down guys and wire rope.

• Comprised of a Malleable Iron base, “U” bolt, and two hex nuts.

• All components are hot dip galvanized to meet ASTM Specification A153.

5/16" Malleable Guy-Clip Allied H-886-

• For 5/16 Strand
• A heavy duty means of securing down guys and wire rope.

• Comprised of a Malleable Iron base, “U” bolt, and two hex nuts.

• All components are hot dip galvanized to meet ASTM Specification A153.

ADSCO Stainless Steel 5/8 Curved Suspension Clamp 11/16 Mounting Hole CSC1

STAINLESS STEEL Adsco Curved Suspension Clamp CSC1 with 11/16 hole for 5/8 Hardware

Adsco Stainless Steel Lashing Wire Clamp LWC-304SS

Stainless Steel Adsco Lashing Wire Clamp
Scope:

This item standard is intended for use in conjunction with CSA standard CAN/CSA-C83. This item is normally mounted on messenger strand and is used to terminate cable lashing wire.
Assembly:
The lashing wire clamp is comprised of two clamp sections, two flat washers, and two hex nut assemblies on a shouldered stud. The stud should key into one clamp section at assembly to prevent stud rotation as the nuts are tightened. This keying feature is constructed to allow proper closing of the jaws. Both ends of the stud should be suitably modified after assembly to prevent loss of the nuts.
Accommodation:
The clamp will accommodate a range of messenger strand from 3/16″ to 9’16” diameter designated strand size

B Cable Suspension Bolt 5/8" X 18" Allied Bolt 8264

Used to secure two cable suspension clamps at opposite sides of utility pole.

• Collars are forged instead of welded for extra strength.
• Bolt provided with cone point at each end to ease starting.
• Hot dip galvanized to meet ASTM Specification F2329.
• Manufacturers mark (ABI) and tensile load designation mark (i.e.10M, 16M, 25M) appear on the unthreaded section of each bolt. ABI marking is registered with the U.S Patent Office per the Fastner Insignia Act.
• Minimum tensile strength: 13,550 lbf.
• Recommended torque value: 73 ft lb.
• Unthreaded section is 6".

B Strand Grounding Clamp "Mailbox Clamp" J7956

This grounding clamp is used to bond the cable sheath to the messenger strand. Clamp body is made with an inside keeper riding on the end of the bolt. 1/2" bolt can be removed to place the clamp over the messenger wire.

Beam Clamp w/ Square Head MSI SI-2181

MSI SI-2181 Beam Clamp w/ Square Head, is used to provide an electrical connection to trailers, mobile homes or other beam structures. The cup point on bolt penetrates through surface paint or oxide for intimate ground to base metal.
Specifications:

• Seperate screws to attach #14 to #6 AWG ground wires
• High strength bronze casting
• UL & CUL Listed
• Bolt Head: Square
• Beam Ground Clamp


  Structure Ground Clamp

Cable Extension Bolt 5/8" x 11" Allied Bolt 2073

• Used for placement of second cable at the same level and side of a pole as the existing cable.

• Cable Extension Bolts are designed to attach to the threaded ends of suspension bolts.

• Internally threaded section is eight inches long.

• External threaded section is three inches long.

• Hot dip galvanized to meet ASTM Specification A153.

Cable Extension Bolt 5/8" x 7" Allied Bolt 2070

• Allied Bolt 2070 Used for placement of second cable at the same level and side of a pole as the existing cable.

• Cable Extension Bolts are designed to attach to the threaded ends of suspension bolts.

• Internally threaded section is four inches long.

• External threaded section is three inches long.

• Hot dip galvanized to meet ASTM Specification A153.

Cable Extension Bracket 17-1/2" To 26" J7920

H-J7920 ARM CABLE EXTENSION
3 x 2-1/2 x 5/16 Angle Size 17-1/2-26 extension from center of Pole.
hot dip galvanized Telephone cable support.

Cable Extension Bracket 26-1/2" - 44-1/2" J7921

H-J7921 ARM CABLE EXTENSION ARM.
3-1/2 x 2-1/2 x 5/16 Angle Size 26-1/2 - 44-1/2 Extension from center of Pole.
hot dip galvanized telephone cable support.

CABLE EXTENSION ARM H-J7921

Cable Suspension 1/4" x 3/8" Crossover Clamp MSI J7930

1/4" to 3/8" Strand. Used to clamp to messengers where the cross at right angles to prevent wear and abrasion. The clamp sections are 1 1/2in wide and 3 1/4in long. Two 1/2in diameter bolts have oval shoulders to prevent turning when tightening. J7930

Cable suspension clamp - Straight H-J7904-ALL-5087 13/16" hole 3/4" hardware

Cable suspension clamp - Straight H-J7904-ALL-5087 13/16" hole 3/4" hardware MPS cable suspension clamps are used with through bolts which serve as a clamping member and are shaped to securely grip messenger wire/strand to the pole.

Cable Suspension Clamp - Straight J1096 11/16" hole

MPS cable suspension clamps are used with through bolts which serve as a clamping member and are shaped to securely grip messenger wire/strand to the pole. fits 1/4 to 7/16 strand BITCH CLAMP

Cable Suspension Clamp Angle J7901 13/16 MOUNTING HOLE

Angle Suspension Clamps with 1/2" track bolts and 13/16" mounting hole

Cable Suspension Clamp Angle J7901A 11/16 MOUNTING HOLE

Angle Suspension Clamps with 1/2" track bolts and 11/16" mounting hole

Cable Suspension, Type C PA422 FIGURE 8 SERPENTINE CLAMP

This clamp incorporates serpentine grooves in the two mating clamp sections to provide superior holding strength of insulated messenger wire.

Communication Arm 3 & 2 Position Steel Under-build, 15° Angled WSO WB2751-B-HDG

HDG Communication Arm 3 & 2 - Position Steel Under-build, 15° Angled
15 degree angled Communication Arm 3 & 2 position Steel Under-build, galvanized for weather protection, and designed to allow for the addition of under-build cables. 36" & 24" in length from pole and 12" between mount holes.
All pole mounting and cable mounting holes are 11/16'' diameter.
WSO WB2751-B-HDG

CORNER ATTACHMENT H-P294 DOUBLE THIMBLE EYE

Features:

• Corner attachment clamps are used for angles of 35 degrees to 60 degrees.
• Accommodates 5/8-inch diameter pole mounting bolt.
• The inner pole mounting surface is curved with integral spurs for contact stability with the pole.
• The integral thimble eyes will accept deadending devices up to 1/2-inch diameter.

Material:

• Ductile Iron - Hot Dip Galvanized

Curved Heavy Duty Suspension Clamp 5/8" MSI H-J7902B

MSI H-J7902B Curved Heavy Duty Suspension Clamp, is constructed with curved ends to prevent damage to the messenger strand when turning small angles. It is used in conjunction with through bolts to serve as clamping member, securely grips messenger strand to the pole. A nut and square washers are used between the clamp and pole to provide proper spacing.
Specifications:

• Firmly grips 1⁄4" (6.6M) to 7⁄16" (16M) diameter messenger strand
• Furnished with two track bolts and a center mounting hole
• constructed of high quality steel, hot-dipped galvanized
• Clamp Bolt Diameter: 5/8"
• Clamp Length: 6"
• Clamp Width: 2-3/16"
• Mounting Hole Diameter: 13/16"

D Lashing Clamp Bug Nut 4040

D Cable Lashing Clamp used in aerial construction to secure terminating lashing wire or ground wire to a strand Attaches to 1/4"(6mm) to 7/16" (16mm) Made in the USA

E Lashing Clamp - Bug Nut H-9053

9053 E Lashing wire clamp Used to secure a terminating lashing wire to the strand. Comprised of a one-piece jaw, two washers, two nuts, and a square shank stud. Bug Nut
Bugnut also stock Hubbell 9000 E Clamp

GROUND BOND 5/8" H-J1163

H-J1163 Ground/Bond 5/8"

MSI galvanized steel ground/bond clamp

• Used to attach ground wires at the nut end of bolts on transmission lines
• Includes two 1½" long clamp sections and one square nut
• Constructed of high quality steel, hot-dip galvanized
• Ground Wire Diameter 3/16" - 3/8"

Grounding Clamp Hubbell GC5006SH

Grounding Clamp, Copper Cable to Cable, Vice Type. 6 Gage & 6-14 Gage conductors
For copper connections-Splice, Loop deadend or service entrance tap or grounding connections • One piece design for easier, faster installation • Bolt head design for use with standard ratchet wrench • Vise design achieves high connector pressure with low wrench force

Guy Clamp One Bolt J1061

Joslyn Guy Clamp 2-Bolt 3/16" - 5/16" H-J926

SPECIAL ORDER

H-J926 Joslyn Guy Clamp 2-Bolt 3/16" - 5/16"
Joslyn Guy Clamps are rolled from carbon steel with straight parallel grooves that will not damage guy strand. Offset guy clamps are designed to give increase holding strength. The clamping bolts have special shoulders to prevent turning when the nuts are tightened,
Specifications:

• Number of Bolts: 2
• Bolt Diameter: 1/2"
• Clamping Length: 3-1/4"
• Clamp Width: 1-9/16"
• For Strand Diameter: 3/16" - 5/16"

Messenger Clamp H-PA166A Messenger Clamp .162 - .257 Strand

0162-.257 Strand or wire for 5/8 Bolt

• Small economical clamp for light duty construction
• A stringing finger is included on the clamping plate
• The back of the clamp body is recessed to fit over nut.
• A second nut secures the clamp plate and assures positive, independent clamping cation regardless of wood shrinkage
• 1-3/4 wide x 2.5" high

Messenger Clamp Heavy Duty H-PA175C Strand Range .430-.630 for .750 hardware

For attaching medium to heavy duty cable on both angle and tangent construction
Two separate clamping plate bolts allow clamping action to be independent of wood shrinkage

Messenger Clamp Medium Duty PA192A .310-.500 STRAND

.310-.500 STRAND .125-.184 GROUND WIRE RANGE
6-inch long curved clamping groove to conform to sag of span. For attaching medium size cable and triplex. Generously belled groove ends for angles. Teeth on feet resists downslotting. Smoothed area for stringing operation. Special nut retaining feature around body mounting bolt hole.

• 6-inch long curved clamping groove to conform to sag of span.
• Generously belled groove ends for angles.
• Teeth on feet resists downslotting.
• Smoothed area for stringing operation.
• For attaching medium size cable and triplex.
• Special nut retaining feature around body mounting bolt hole.

Messenger Clamp w/ Hook J2235

The H-J2235 is used on .250 inch insulated messenger wire.These clamps are used for tangent construction or angles to 10 degrees. The hook is provided for stringing and safety. The clamp surface length is 1 7/8". The H-J2235 is used for heavier construction.

Messenger Clamp W/Hook J2235

Messenger Clamp w/Hook J2245 3.25 inch wide

The H-J2245 is used on .250 inch insulated messenger wire.These clamps are used for tangent construction or angles to 10 degrees. The hook is provided for stringing and safety. The clamp surface length is 3 1/4". The H-J2245 is used for heavier construction.

Messenger Clamp w/Hook J2245

Messenger Clamp w/Hook MB-62 .25-.61 STRAND

• .25-.61 STRAND .16-.25 GROUND WIRE 5/8 Bolt
• Curved groove for more cable support
• Lip on bottom groove kicks upward to support cable during installation
• Hook for supporting messenger during stringing operation
• Independent clamping - messenger remains clamped if pole shrinkage occurs
• Provides 1½" pole clearance
• Constructed of ductile iron, hot-dip galvanized

Messenger Clamp w/Hook MB-62 .25-.61 STRAND

Messenger Clamp w/Hook MBA-72 .25-.72 STRAND

.25-.72 STRAND .12" - .25" GROUND WIRE

• Curved messenger groove for better support
• Body tapped for 5/8" bolt
• Hook for supporting messenger during stringing operation
• Messenger groove lip kicks-up to support cable during installation
• Independent clamping- clamp remains tight on messenger if pole shrinkage occurs
• Teeth on legs to resist movement

Material: Aluminum Alloy
Messenger Clamp w/Hook MBA-72 .25-.72 STRAND.

Messenger Clamp w/Hook MSBC-56 .398" - .56" range

May be used to support fiber optic cable, Can be mounted on round or flat surfaces, on a pole, or on a standoff bracket, Vertical fingers support cable during stringing operation, Clamping Range: .398" - .56", Mounting hole is 11/16"
Material:

• Body and Keeper: Aluminum Allo

• Hardware: Steel; Hot Dip Galvanized

Messenger Clamp w/Hook PA292X

The PA292X is used on .109 inch to .134 inch bare or insulated messenger wire. The hook serves as a safety device and can be used in the stringing of the cable. The clamp sections and hook accommodate a 5/8-inch diameter pole mounting bolt. The clamp surface length is 1-3/4-inches.

PA292X Messenger Clamp w/Hook

Messenger Clamp w/Hook PA296X

The PA296X is used on .250 inch insulated messenger wire.These clamps are used for tangent construction or angles to 10 degrees. The hook is provided for stringing and safety. The clamp surface length is 3-1/4-inches.
The PA296X is used for heavier construction.
PA296X Messenger Clamp w/Hook.

MESSENGER HANGER 1/4"-3/8" STRAND MSI J1070

The Maclean Senior J1070 cable messenger hanger is hot formed from 1/2" x 2" open hearth steel with a specially curved groove which permits its use on corners as well as on straight runs. Two 1/2" high carbon steel track bolts clamp the strand.
Mounting holes are 9/16" and 11/16" in diameter for a 1/2" lag screw and 5/8" through bolt.

ONE Bolt Suspension Clamp - Straight J1095 11/16" Hole

Reinforce Brace 1-3/8" Allied Bolt 8001

Used to support the outer end of extension bolts when installing a parallel line to existing aerial plant.

• The distance between the Suspension Clamp and the above mounting hole is 8-3/4".
• Stock size is 1/8" x 1-3/8".

• Stamped from AISI 1018 steel.

• Hot dip galvanized to meet ASTM Specification B695.

Reinforcing Strap 1/8" x 1-3/4" J7905

Reinforcing Straps support the messenger bolt at locations of heavier than normal loading stress, such as long spans and are used with cable suspension clamps. The lower hole fits over the messenger bolt and the top end is fastened to the pole with a lag screw.

• Used in aerial construction as an added support for three-bolt suspension clamps.
• Stock size is .125 x 1-3/8".
• The distance between the Suspension Clamp and the above mounting hole is 5-7/8".
• Mounting hole diameters are both 11/16".
• Stamped from AISI 1018 steel.
• Hot dip galvanized to meet ASTM Specification B695.

Reinforcing Strap 1/8" x 2" J7908

Reinforcing Straps support the messenger bolt at locations of heavier than normal loading stress, such as long spans and are used with cable suspension clamps. The lower hole fits over the messenger bolt and the top end is fastened to the pole with a lag screw.

• Used in aerial construction as an added support for three-bolt suspension clamps.
• Stock size is .125" x 2".
• The distance between the Suspension Clamp and mounting hole is 5-7/8".
• Hole diameters are 11/16" and 25/32".

• Stamped from AISI 1018 steel.

• Hot dip galvanized to meet ASTM Specification B695.

Serving Sleeve 1/2" Hubbell 6456

Hubbell 6456 Serving Sleeve, for 1/2" diameter strand. For holding down the loose end of guy strand projecting beyond the guy clamp. Serving sleeves have a flared end to speed application. Hot dip galvanized.
Specifications:

• Coating: Galvanized, ASTM A-153
• Material: Steel
• Length: 2.25"

Serving Sleeve 1/4" Hubbell 6452

Hubbell 6452 Serving Sleeve, for 1/4" diameter strand. For holding down the loose end of guy strand projecting beyond the guy clamp. Serving sleeves have a flared end to speed application. Hot dip galvanized.
Specifications:

• Coating: Galvanized, ASTM A-153
• Material: Steel
• Length: 1.38"

Serving Sleeve 3/8" Hubbell 6454

Hubbell 6454 Serving Sleeve, for 3/8" diameter strand. For holding down the loose end of guy strand projecting beyond the guy clamp. Serving sleeves have a flared end to speed application. Hot dip galvanized.
Specifications:

• Coating: Galvanized, ASTM A-153
• Material: Steel
• Length: 1.75"

Serving Sleeve 5/16" Hubbell 6453

Hubbell 6453 Serving Sleeve, for 5/16" diameter strand. For holding down the loose end of guy strand projecting beyond the guy clamp. Serving sleeves have a flared end to speed application. Hot dip galvanized.
Specifications:

• Coating: Galvanized, ASTM A-153
• Material: Steel
• Length: 1.50"

Serving Sleeve 7/16" Hubbell 6455

Hubbell 6455 Serving Sleeve, for 7/16" diameter strand. For holding down the loose end of guy strand projecting beyond the guy clamp. Serving sleeves have a flared end to speed application. Hot dip galvanized.
Specifications:

• Coating: Galvanized, ASTM A-153
• Material: Steel
• Length: 2.00"

Sidewalk Guy Clamp DG5D1 3 WIRE 2.5" PIPE HUBBEL POWER SYSTEMS

STRAND END FITTING FOR QUEENS POST
Sidewalk Guy End Fitting, with three clamps. Used where space is not available for standard guying. For 2 1/2" diameter pipe (Not included). Hot dip galvanized.

Sidewalk Guy Clamp End J0522 Pipe size: 2" & 2-1/2" requires J931

These cast iron fittings are used with standard pipe near sidewalks and buildings where there is insufficient space for standard guying and where head clearance must be maintained.The J0522 end fitting requires a J931 guy clamp which must be ordered separately.

Sidewalk Guy Clamp End J1502 Pipe size: 2"

These cast iron fittings are used with standard pipe near sidewalks and buildings where there is insufficient space for standard guying and where head clearance must be maintained.

Sidewalk Guy Pole Plate J0521 Pipe size: 2"- 2 1/2"

These cast iron fittings are used with standard pipe near sidewalks and buildings where there is insufficient space for standard guying and where head clearance must be maintained.

Sidewalk Guy Pole Plate J1501 Pipe size: 2"

These cast iron fittings are used with standard pipe near sidewalks and buildings where there is insufficient space for standard guying and where head clearance must be maintained.

Straight Suspension Clamp 5/8" MSI H-J25088.1

MSI H-J25088.1 5/8" Straight Suspension Clamp, with Flat Keeper Plate, is used with through bolts to serve as clamping member. This Flat 3-hole clamp securely grips messenger strand to pole, it uses a nut and square washer that is used between the clamp and pole for proper spacing.
Specifications:

• Firmly Grips 1/4" (6.6m) to 7/16" (16m) diameter messenger strand
• 3-Bolts,Flat
• Clamp Bolt Diameter: 1/2"

• Clamp Length: 5-3/4"
• Mounting Hole Diameter: 11/16" X 15/16"
• Constructed of high quality steel, hot-dipped galvanized

Tangent Support Clamp .148" to .250" for 5/8" Bolt Allied Bolt 5904
