24" Overhead Fiber Optic Cable Sheave Condux 08637825
3" X 24 (22) FO OVERHEAD FIVER OPTIC SHEAVE
Specially designed in cooperation with Alcoa Fujikura Ltd. for guiding fiber optic or CATV cable safely and efficiently. Condux Cable Sheaves feature an innovative hanger arm that eliminates the possibility of cable coming off the sheave or binding against the support arm. With the removal of a pin, the hanger arm separates and allows cable to be slipped in easily, even at midpoints. Aka Bicycle Wheel.
12-inch (305 mm) or 24-inch (610 mm) sheave diameters allow for a gentle cable arc. Aluminum sheave construction means durability with less weight. Maximum capacity is 1,500 lbs.
24" Underground Fiber Optic Cable Sheave Condux 08637800
The Underground Fiber Optic Sheave has all the features of the Overhead Sheave but with an additional second arm for convenient tie-off. Replacement Sheaves available.
Specially designed in cooperation with Alcoa Fujikura Ltd. for guiding fiber optic or CATV cable safely and efficiently, Condux Cable Sheaves feature an innovative hanger arm that eliminates the possibility of cable coming off the sheave or binding against the support arm. With the removal of a pin, the hanger arm separates and allows cable to be slipped in easily, even at midpoints.
12-inch (305 mm) or 24-inch (610 mm) sheave diameters allow for a gentle cable arc. Aluminum sheave construction means durability with less weight. Maximum capacity is 1,500 lbs.
4K Single Hooked Hanger Sheave Aluminum 5"X11" Condux 08042611
Tie off in manhole to guide cable into and out of duct. 4,000 lbs cable tension load capacity. For less demanding cable pulling applications than Condux 10,000 lbs sheaves, replacement Sheaves available.
Sheave size: 5" X 11"
127 X 279(mm)
Forged hook with 1.12" opening
Material: Aluminum
Alloy Capstan 7" GMP 10727
This general purpose capstan is used for a wide variety of pulling and hoisting applications. Cast from a high strength aluminum alloy for low weight. Will fit on any 2-7/16 in. (62 mm) diameter winch extension shaft equipped with a bayonet or pin type mount. The working surface is 7-1/4 in. diameter x 8 in. (184 mm x 200 mm) wide. The maximum allowable pull is 4000 lbs. (1814 kgs).
Cable Feeding Sheave 1 1/2" Condux 08617215
Condux 08617215 Cable Feeding Sheave plugs into conduit in manhole wall, guiding cable safely into conduit regardless of pulling angle.
Specifications:
Slot Width 1.04"
Slot Length 5"
I.D Tube Width 1.25"
O.D. Tube Width 1.44"
Load Capacity 1500 Lbs
Cable Feeding Sheave 1-1/4" Condux 08617312
Condux 08617312 Cable Feeding Sheave plugs into conduit in manhole wall, guiding cable safely into conduit regardless of pulling angle.
Specifications:
Slot Width 0.88"
Slot Length 5"
I.D Tube Width 1.06"-1.19"
Load capacity 1500"
Cable Feeding Sheave 2" Condux 08617220
Condux 08617220 Cable Feeding Sheave plugs into conduit in manhole wall, guiding cable safely into conduit regardless of pulling angle.
Specifications:
Slot Width 1.38"
Slot Length 6"
I.D Tube Width 1.75"-1.95"
Load capacity 2600"
Cable Feeding Sheave 3" Condux 08617230
Condux 08617230 Cable Feeding Sheave plugs into conduit in manhole wall, guiding cable safely into conduit regardless of pulling angle.
Specifications:
Slot Width 2.25"
Slot Length 12"
I.D Tube Width 2.62"
O.D Tube Width 2.95"
Load capacity 4800"
Cable Feeding Sheave 4" Condux 08617200
Condux 08617200 Cable Feeding Sheave plugs into conduit in manhole wall, guiding cable safely into conduit regardless of pulling angle.
Specifications:
Slot Width 3.00"
Slot Length 12"
I.D Tube Width 3.50"
O.D Tube Width 3.95"
Load capacity 6500"
Cable Feeding Sheave 5" Condux 08617250
Condux 08617250 Cable Feeding Sheave plugs into conduit in manhole wall, guiding cable safely into conduit regardless of pulling angle.
Specifications:
Slot Width 3.75"
Slot Length 14"
I.D Tube Width 4.50"
O.D. Tube Width 4.90"
Load Capacity 6500 Lbs
Cable Feeding Sheave for 2" Duct Schedule 40 GMP 70563
The GMP 70563 Cable Feeding Sheave, for the 2" Pipe schedule 40, slides into the end of conduit in a manhole wall, allowing the cable being fed into the conduit to roll smoothly over sheave from all angles. It has a frame made of steel for durability while the sheave is made from aluminum alloy with self lubricating bearings.The sheave has a split tube for easy convenient removal after cable is installed.
Cable Feeding Sheave for 3" Duct Schedule 80 GMP 70570
The GMP 70570 Cable Feeding Sheave, for the 3" duct schedule 80, slides into the end of conduit in a manhole wall, allowing the cable being fed into the conduit to roll smoothly over sheave from all angles. It has a frame made of steel for durability while the sheave is made from aluminum alloy with self lubricating bearings.The sheave has a split tube for easy convenient removal after cable is installed. * GMP 70570 ONLY
Cable Feeding Sheave for 4" Duct Schedule 40 GMP 70565
The GMP 70565 Cable Feeding Sheave, for the 4" duct schedule 40, slides into the end of conduit in a manhole wall, allowing the cable being fed into the conduit to roll smoothly over sheave from all angles. It has a frame made of steel for durability while the sheave is made from aluminum alloy with self lubricating bearings.The sheave has a split tube for easy convenient removal after cable is installed.
Cable Feeding Sheave for 4" Duct Schedule 80 GMP 70566
The GMP 70566 Cable Feeding Sheave, for the 4" duct schedule 80, slides into the end of conduit in a manhole wall, allowing the cable being fed into the conduit to roll smoothly over sheave from all angles. It has a frame made of steel for durability while the sheave is made from aluminum alloy with self lubricating bearings.The sheave has a split tube for easy convenient removal after cable is installed. * GMP-70566 ONLY
Cable Shoe CABLE BENDING SHOE 3.5" GMP 86571
Cable Shoe CABLE BENDING SHOE Help protect cables from sharp edges in and around manholes and conduit systems. Available in 2 sizes; 3" and 3.5". Made of cadmium plated, 13 gauge steel with a protective polymer coating to extend the life. Each shoe has a tieoff hole at either end for increasing stability during the pulling of cables through it. The trough like steel section is bent into a 75 degree arc with an extended end for easier insertion into duct.
Condux 08042100 Cable Bending Shoe
Condux 08042100 Cable Bending Shoe I.D 3.19/O.D 3.44
Protects cable from corner abrasion during pulling operations. Rugged, high-impact plastic.
Corner Cable Guide 5" Condux 08043200
Condux 08043200 Corner Cable Guide for pulling cable into manhole.
Aluminum and Nylatron® sheaves for pulling cable into manholes. 5,000 lbs. (22,240 N) cable tension load capacity.
Corner Cable Guide 8" Condux 08088800
Condux 08088800 Corner Cable Guide for pulling cable into manhole.
- Maximum Cable Diameter: 8.25"
- Maximum Working Load: 5,000 lbs.
- Aluminum and Nylatron Cable Sheaves compatible
- Replacement Sheave/Rollers: 08087911 8 x 11"
*Condux 08091440 Support Bar not included
Hooked Hanger Sheave 4 X 20", 10K Rating Condux 08042420
Condux 08042420 Hooked Hanger Sheave 4 X 20, 10K Rating
Tie off in the manhole to guide cable into the duct. Also
used with alignment arm for cable removal. Hinged yoke
for easy cable installation and removal. 10,000 lbs.
(44,480 N) cable tension load capacity. Alignment
arm sold separately.
Specification:
- Steel welded frame
- Nylon cable protectors
- Cast aluminum sheaves
- Forged hook with 1./12" opening
- Width: 4.75" (120 mm)
- Maximum Cable Diameter: 4" (102 mm)
- Minimum Bending Radius: 8.5" (215 mm)
- Shaft: 1.25" (32 mm)
- Sheave Diameter: 20" (508 mm)
- Maximum Tension LB: 1,000 lbs. (44,480 N)
- Material: Aluminum
Manhole Sheave 4" GMP 70284
GMP 70284 4" Manhole sheave The manhole sheave or "Pittsburgh" is used to guide pulling line or cable over the manhole edge when placing and removing cable in manholes which are equipped with pulling in irons to support a sheave and a shackle assembly. Also called a Lip roller
Nylatron® Cable Feeding Sheave 1 1/2" Condux 08617415
Condux 08617415 Nylatron® Cable Feeding Sheave plugs into conduit in manhole wall, guiding cable safely into conduit regardless of pulling angle.
Specifications:
Slot Width 1.04"
Slot Length 5"
I.D Tube Width 1.25"
O.D. Tube Width 1.44"
Load Capacity 1500 Lbs
Nylatron® Cable Feeding Sheave 2" Condux 08617420
Condux 08617420 Cable Feeding Sheave plugs into conduit in manhole wall, guiding cable safely into conduit regardless of pulling angle.
Specifications:
Slot Width 1.38"
Slot Length 6"
I.D Tube Width 1.75"-1.95"
Load capacity 2600"
Nylatron® Cable Feeding Sheave 3" Condux 08617430
Condux 08617430 Nylatron® Cable Feeding Sheave plugs into conduit in manhole wall, guiding cable safely into conduit regardless of pulling angle.
Specifications:
Slot Width 2.25"
Slot Length 12"
I.D Tube Width 2.62"
O.D Tube Width 2.95"
Load capacity 4800"
Nylatron® Cable Feeding Sheave 4" Condux 08617440
Nylatron® Condux 08617440 Cable Feeding Sheave plugs into conduit in manhole wall, guiding cable safely into conduit regardless of pulling angle.
Specifications:
Slot Width 3.00"
Slot Length 12"
I.D Tube Width 3.50"
O.D Tube Width 3.95"
Load capacity 6500"
Replacement Sheave Pin 1-5/16 X 5" for Jamb Skid GMP 71717
GMP 71717, Replacement Sheave Pin to lock the jamb skid height and secure sheave or quadrant block.
The 70640 Jamb Skid is used to support quadrant block and sheave when pulling cable through underground conduit.
Sheave Pin Diameter: 1-5/16 X 16"(33mm)
Underground Fiber Optic Sheave 24" & Shackle Assembly GMP 71560
GMP 71560 Underground Fiber Optic Sheave 24" & Shackle Assembly
Underground 24 in. fiber optic sheave and shackle assembly - working load 2,000 lbs. Designed to accommodate the special handling needs of pulling fiber optic cable. Among the unique needs of pulling fiber optic cable. Among the unique features are a lightweight design, one size shackle and the reduction of loose parts.
