Lemco 6300C, 2" Reel Collar or Spool Collar, is used to hold the Reel that is found on the Reel Bar used on Lemco Trailers.
This Arbor Collar can be used with all Lemco Trailers. *Must buy TWO each to make a pair*

The 5254P Smallest trailer packs a big payload and withstands full-time construction duty. Standard equipment includes: license plate bracket, safety chains, reflectors, light group, reel collars (1 set). Specify ball coupler or pintle eye.

Price reflects drop ship only. Shipping from our stock incurs freight inbound costs.

Reel Capacity(diam x w): 54 x 56"
Gross Vehicle Weight: 2,000 (lbs.)
Overall Dimensions: 96 x 70 x 44"
Shipping Weight: 200 (lbs.)

Slabach Hydraulic Re-wind

8" Pneumatic Tire
Maximum R.P.M. is 65
Speed on drive wheel (outside edge of tire) is 242 feet per minute @ 4 gpm
Speed on drive wheel w/ 4' spool was 110' fmp. Torque of 360 lb @ 1,000 psi.
Variable speed
Rewinds in either direction.

The 6354P single-arbor trailers features 63" of usable arbor space, a 3500 lb. drop axle, for a
sleek profile with a low center of gravity. Standard equipment Price reflects drop ship only. includes: leaf springs, license plate bracket, safety chains, reflectors, light group, reel collars(1 set).

Price reflects drop ship only. Shipping from our stock incurs freight inbound costs.

Reel Capacity(diam x w): 54 x 63"
Gross Weight: 2,240 (lbs.)
Overall Dimensions: 116 x 89 x 45"
Shipping Weight: 375 (lbs.)

The 6372P single-arbor trailers features 63" of usable arbor space, a 3500 lb. drop axle, for a
sleek profile with a low center of gravity. Standard equipment includes: leaf springs, license plate bracket,
safety chains, reflectors, light group, reel collars(1 set).

Price reflects drop ship only. Shipping from our stock incurs freight inbound costs.

Reel Capacity(diam x w): 72 x 63"
Gross Weight: 2,240 (lbs.)
Overall Dimensions: 118 x 89 x 52"
Shipping Weight: 405 (lbs.)

Lemco Adjustable Pintle Eye Single-Arbor Trailer features ST 205-75R14C tires.
Please Note:

• Vehicular brakes are not provided with trailer
• A loading dock is required for trailer delivery (Additional Charges for Lift Gate)
• excludes wheel chalks and holder.

Dual trunk and single feeder capacity is made available by this unit. Standard equipment includes: license plate bracket, safety chains, reflectors, and light group. The 7457 also includes leaf springs, two sets of reel collars and a 3500 lb. drop axle. Specify ball coupler or pintle eye.

Price reflects drop ship only. Shipping from our stock incurs freight inbound costs.

Reel Capacity(diam x w): 42 x 34"(front) 54 x 62"(rear)
Gross Vehicle Weight: 2,950 (lbs.)
Overall Dimensions: 112 x 89 x 45"
Shipping Weight: 460 (lbs.)

The 63102P single-arbor trailers features 63" of usable arbor space, a 3500 lb. drop axle, for a
sleek profile with a low center of gravity. Standard equipment includes: leaf springs, license plate bracket,
safety chains, reflectors, light group, reel collars(1 set).

Price reflects drop ship only. Shipping from our stock incurs freight inbound costs.

Reel Capacity(diam x w): 102 x 63"
Gross Weight: 2,999 (lbs.)
Overall Dimensions: 124 x 89 x 68"
Shipping Weight: 626 (lbs.)

SLABACH PWR PK 6.5HP

Engine -6.5HP Honda

Pump - 5.0 GMP @ 3630 RPM
Valve - Four-way Directional with Relief
Hydraulic Pressure - 2000 PSI max.
Reservoir - 5 US Gallons (1150 cu. inches)
Weight - 95 Pounds Dry

The solar guide is an arrow board trailer that is built to preform while still offering a great value. 11 pre-programmed display functions are...

* Please call for freight quote *

The only cable reel trailer on the market that can load and unload a reel using the tow vehicle. The Reel EZ35 Cable Reel Trailer is perfect for handling up to 5' diameter cable reels. Reel EZ Trailer Model 35

Payload Rating: 2900 lbs
Reel Diameter (max): 60"
Reel Width (max): 60"
Trailer Length: 112"
Trailer Width: 88"
Tires: 7.5x14 (6 ply)

* Please call for freight quote *

The only cable reel trailer on the market that can load and unload a reel using the tow vehicle. The Inner-Duct Reel EZ Trailer handles up to 8' diameter reels with ease. Perfect for Inner-Duct reels, larger cable reels, strand reels, wire ropes reels and more.

Payload Rating: 2820 lbs
Reel Diameter (max): 96"
Reel Width (max): 60"
Trailer Length: 112"
Trailer Width: 88"
Tires: 7.5 x 14 (6 ply)

The 45 is designed for those who need a trailer to handle lighter, smaller spools and do not want to pay for the extra capacity of a larger trailer.

Slabach I-60 Wheeler Reeler Features 6,000 pound payload capacity, manual hydraulic pump, flow divider, internal cylinders, electric brakes, breakaway kit, electric junction box, drop leg jack, safety chains...

Slabach I-85 Wheeler Reeler Features 8,500 pound payload rating, manual hydraulic brakes, flow divider, internal cylinders, electric brakes, breakaway kit, electric junction box, drop leg jack, safety chains...

REMOTE STAND & TOOL BOX ONLY-- SKU: 08675675 WEIGHT:2,500.00 LBS
Fiber Optic Cable Puller Options: Condux 08690001 Fiber Optic Cable Puller Package Condux 08690055 Fiber Optic Cable Puller Package 3 With Chart Recorder

Over the course of our 35 year history in the trailer manufacturing industry, Brooks Brothers has become a....

The GMP "SideWinder", Trailer Mounted Fiber Optic Puller

The GMP "SideWinder", Trailer Mounted Fiber Optic Puller

* Please call for freight quote *

Provides up to 7,500 lbs. of continuous pulling applications. Designed for installing underground cable, the APS75 is completely self contained and transport easily from job-site to job-site. This trailer is made with precision manufacturing, to the highest standards. Each puller is backed with years of underground cable pulling experience and a commitment to quality service.
Features:

• Comes standard with 2600 ft. of Anti-twist Rope
• Digital Monitoring System with USB connection to record & download pulling operations
• Rotating Pulling Arm pivots 15 degrees in either direction
• Wired Remote Control
• Hydraulic tool circuit to operate additional tools
• Easy access diesel engine for maintenance
• Electric brakes
• Numerous adjustable supports for optimum stability
• DOT Certified Trailer
