You are here: Home > Aerial Lineman Tools > Stringing Block
We found 27 results matching your criteria.
Stringing Block
Sort By:
1 2
Sherman Reilly BH-5L  # 1 BALL HOOK # 1 BALL HOOK Sherman Reilly BH-5L

Sherman Reilly BH-5L #1 BALL HOOK for stringing block. Socket Connector.



Our Price: $11.49
Sherman CB-55 Ball U Clevis Ball U Clevis Sherman Reilly CB-55

Ball Clevis for use with Stringing Block PART SHER CB-55 Socket Connector.

Our Price: $15.58
Sherman Reilly YCB-65A-WAG-8 Y Ball Clevis WAG #8 Y Ball Clevis WAG #8 Sherman Reilly YCB-65A-WAG-8

Ball Clevis for use with Stringing Block PART SHER YCB-65A Y BALL Socket Connector.

Our Price: $15.70
Sherman Reilly 554332  Detent "L" Handle Pin 7/16" Detent "L" Handle Pin 7/16" Sherman Reilly 554332

Detent "L" Handle Safety Locking Pin w/chain for Sherman Reilly 016-010-01 Cross-arm Bracket.
Pin Diameter: 7/16"

Our Price: $15.71
Sherman Reilly SHER ASBE-55  NO. 6 OVAL EYE Ball Socket NO. 6 OVAL EYE Ball Socket Sherman Reilly ASBE-55

Oval Eye for use with Stringing Block
Sherman Reilly ASBE-55 NO. 6 OVAL EYE Ball Socket Connector.

Our Price: $19.07
Condux CON-21003415 Latch Ball Safety Hook Latch Ball Safety Hook Condux 21003415

Condux CON-21003415 Latch Ball Safety Hook. All block fittings fit into the ball adapter that comes standard with the Sherman Reilly Universal Stringing Block.

Our Price: $24.29
Reliable SBCAB - Crossarm Bracket Adapter Crossarm Bracket Adapter - Reliable SBCAB

Crossarm Bracket Adapter

The REL-SBCAB* Crossarm Bracket Adapter allows t
hree mounting lugs on the frame offering multiple mounting
angles. For use with the REL-SB7 Universal Stringing Block.

Our Price: $32.00
SHER 016-010-01 CROSSARM BRACKET CROSSARM BRACKET/R SHER 016-010-01

SHER 016-010-01 CROSSARM BRACKET/R

REFURBISHED CROSS-ARM BRACKET

**OUT OF STOCK**

Our Price: $45.50
Sherman Reilly XA-3-WSE-X Crossarm Bracket Crossarm Bracket Sherman Reilly XA-3-WSE-X

Sherman Reilly Crossarm Bracket or Cross-Arm Bracket Quick Release Bracket allows for 5 block positions: 0, 22, 45, 68, and 90 degrees.6.5" high x 4.5" wide Xarm Bracket - Cross arm - Maclean




Our Price: $54.32
Reliable REL-SB7 - Universal Stringing Block Power Roller Sherman Reilly Universal Stringing Block Power Roller - Reliable SB7

Universal Stringing Block Power Roller - Reliable REL-SB7 Sherman Reilly

This lightweight, strong, and versatile 7” stringing block
will be a valuable addition to any line stringing inventory.
This unit will provide dependable service under the extreme
conditions common to the Utility Line Construction Industry.
The groove is profile machined to provide precision sagging
and smooth operation. (Up to 2” Max. Conductor)

***Reliable SB7 stringing blocks do not come with a clevis or hook SOLD SEPARATELY***

Our Price: $115.00
Condux 21021122 Universial Stringing Block - 7" Aluminum Universial Stringing Block - 7" Aluminum Condux 21021122



  • Attaches in any one of five positions without extra fittings.
  • Universal model can be used as suspension block on an insulator, pole bracket or cross arm.
  • Spring loaded gate.
  • Safety locking pin.
  • Made of high-strength cast aluminum alloy

    These stringing blocks do not come with a clevis or hook installed
    clevis or hook SOLD SEPARATELY


Our Price: $123.54
Condux 21015026 Universial Stringing Block - 7" Urethane Lined Universal Stringing Block - 7" Urethane Lined Condux 21015026


  • Attaches in any one of five positions without extra fittings.
  • Universal model can be used as suspension block on an insulator, pole bracket or cross arm.
  • Spring loaded gate.
  • Safety locking pin.
  • Lined with urethane coating.
    Clevis or Hook SOLD SEPARATELY


Our Price: $161.33
Sherman Reilly XS 100-B Stringing Block Stringing Block Sherman Reilly XS100B

The Sherman + Reilly XS-100B Universal Stringing Block is a light-weight, yet exceptionally rugged, reliable, and durable distribution stringing block.Exceptional versatility in how and where it may be deployed and in the range of installation problems it can help solve.
2,500 lb. maximum working load. Maximum conductor O.D. is 1.75"

***Sherman Reilly stringing blocks do not come with a clevis or hook SOLD SEPARATELY***

Our Price: $165.33
Sherman Reilly XS 100-B Stringing Block w/ Nylatron Stringing Block Sherman Reilly XS-100B-NY

The Sherman + Reilly XS-100B-NY NYLATRON Universal Stringing Block is a light-weight, yet exceptionally rugged, reliable, and durable distribution stringing block. Combined with its family of associated hardware and accessories, it affords utilities and their contractors exceptional versatility in how and where it may be deployed and in the range of installation problems it can help solve. 2,500 lb. maximum working load. Maximum conductor O.D. is 1.75"
***Sherman Reilly stringing blocks do not come with a clevis or hook SOLD SEPARATELY***

Our Price: $173.33
Sherman Reilly XS-100B-U Universal Stringing Block with Urethane Lined Sheave Universal Stringing Block with Urethane Lined Sheave Sherman Reilly XS-100B-U

Sherman & Reilly urethane-lined aluminum sheaves are made identically to polished-groove sheaves (above) except that a premium-grade polyurethane lining is cast-in-place on the sheaves’ conductor-contact surface. The properties of the urethane and casting it in place on the bare sheave together assure a high-precision profile of the lined sheave. The urethane’s formulation assures resiliency to cushion conductors, as well as assures hardness, high load-bearing capacity, impact resistance, abrasion resistance, resistance to compression-set, and resistance to oil, ozone, and other environmentals – all of which contribute to long useful life, even under harsh field conditions. A-scale durometer hardness of the lining is 90-92. Blocks with urethane-lined sheaves are especially appropriate for stringing conductor, static wire, and fiber optic cables. However, they typically cost ~ 25% more than polished groove.
Specifications:

  • Height Strength, Low Weight
  • Positive Locking handle ( a secure spring loaded latch and large-ID Pull-Loop) on the side gate assembly for easy conductor clip-in and for easy conductor clip-in and for hot-stick operations
  • Maximum Working Load; 2500 lbs.
  • Efficiency: 98%
  • Maximum Conductor OD: 1-3/4"
  • Sheave OD:7"
  • Sheave Groove Radius: 1"
  • Sheave Throat Width: 3-3/16"
  • Sheave Rim Width; 3"
  • Overall Width: 7"
  • Overall Height: 14-11/16" with bracket
  • Overall Height: 15-13/16" without bracket
  • Frame Material; A356-T6 Aluminum (Virgin)
  • Sheave Material: Ductile Iron
  • Sheave Lining: Urethane
  • Hanging Hardware: Socket Connector

Our Price: $202.88
Sherman Reilly  9511-PG Block & Swivel Safety Hook 6" Block & Swivel Safety Hook 6" Sherman Reilly 9511-PG

The 9511 block, or big little block, is little in overall length and weight but big in sheave and load capacity. Side opening for ease in placing in hoisting line. Safety locking pin permits easy opening, positive locking and is captive to blocks, no parts to drop or lose. Frame of high strength aluminum alloy, ribbed for extra strength and rigidity. Integral guard prevents wedging of lines. Sheaves mounted on anti-friction ball bearings are available with polished aluminum, neoprene lined, urethane lined, or ductile iron. Urethane lining recommended when wire rope hoisting lines are to be used. Snatch Block

Designed for Overhead Ground Wires, Ideal for use with Transformer Gin
Size: 6"
Wire OD: 3/4"
Load capacity: 3,000 Ibs
Swivel safety Hook


Our Price: $421.43
Jameson SHV-8 FIBER OPTIC CABLE SHEAVE AERIAL BUDDY 8" 8" Fiber Optic Cable Sheave Aerial Buddy Jameson SHV-8



Jameson SHV-8 Aerial Buddy 8" Polymer Sheave -Yellow, Maximum Load to 1600 lbs.

Forget heavy metal sheaves that require time and labor intensive trying to maintain the proper angle, the Jameson Aerial Buddy cable sheave self-levels to a 20° angle – strapping is optional! Constructed of a Chemical, Corrosion, and UV resistant polymer that has been electrically insulated, the reinforced frame and wheel offer
longer life, reduce installation fatigue and weighs 40% less than the lightest aluminum aerial sheaves. The Cable Guard ensures cables, pull tapes and pulling grips pass through the sheave easily without derailing; the spring-loaded retracting design allows for fast, simple loading or unloading of fiber optics. ALSO Available in an 8" model for straight pulls, or 24" model for set-up, take-down & turns, the Aerial Buddy delivers maximum maneuverability and unrestricted mounting options with lift hoists that swivel and rotate up to 360°. Overhead cable placing is even easier with the addition of optional slip hook and safety shackle accessories.

**OUT OF STOCK**
Jameson SHV-8 Includes: 1 Jameson Aerial Buddy 8" Polymer Sheave -Yellow

Our Price: $544.13
Sherman Reilly 74 series 700654 10" High Strength Aluminum Stringing Block Sherman Reilly 74 series 700654 10" High Strength Aluminum Stringing Block

Sherman Reilly 74 series 700654 10" High Strength Aluminum Stringing Block
The 74 series single conductor stringing block is used mostly for new-line construction. It offers a conductor guard, which is an integral part of the aluminum alloy frame. This allows for the conductor to only come in contact with smooth aluminum surfaces. Should the conductor or pulling line come out of the sheave groove, the smooth contoured conductor guards will guide it back into the sheave groove. This virtually eliminates the chance of the conductor, pulling line, or pilot line, wedging between the sheave and the side frame.
Specification:

  • Outside Sheave Diameter: 10"
  • Rim Width: 1-7/8"
  • Bottom Groove Diameter: 7-11/16" - 7-15/16"
  • Point of Connection to bottom of groove: 8 7/8"
  • Throat - Height: 4 13/16" , Width: 2-1/8"
  • Overall Length: 18-3/8"
  • Max Outside Width: 4-1/4"
  • Radius Bottom Groove: 17/32"
  • Max Working Load: 6,500 lbs.

Our Price: $661.42
Sherman Reilly 74 series 700775 14" High Strength Aluminum Stringing Block Sherman Reilly 74 series 700775 14" High Strength Aluminum Stringing Block

Sherman Reilly 74 series 700775 14" High Strength Aluminum Stringing Block
The 74 series single conductor stringing block is used mostly for new-line construction. It offers a conductor guard, which is an integral part of the aluminum alloy frame.This allows for the conductor to only come in contact with smooth aluminum surfaces. Should the conductor or pulling line come out of the sheave groove, the smooth contoured conductor guards will guide it back into the sheave groove.This virtually eliminates the chance of the conductor, pulling line, or pilot line, wedging between the sheave and the side frame.
Specification:

  • Outside Sheave Diameter: 14 1/2"
  • Rim Width: 2 1/8"
  • Bottom Groove Diameter: PG2: 12" , Other3: 9 1/2"
  • Point of Connection to bottom of groove: 9-1/2"
  • Throat - Height: 5-1/2" , Width: 2-3/8"
  • Overall Length: 23-7/16"
  • Max Outside Width: 5-1/8"
  • Radius Bottom Groove: 21/32"
  • Max Working Load: 7,500 lbs.
*ONE BLOCK PER PURCHASE

Our Price: $740.00
Jameson SHV-24 Fiber Optic Cable Sheave Aerial Buddy 24" 24" Fiber Optic Cable Sheave Aerial Buddy Jameson SHV-24



Jameson SHV-24 Aerial Buddy 24" Polymer Sheave -Yellow, Maximum Load to 1600 lbs.

Forget heavy metal sheaves that require time and labor intensive trying to maintain the proper angle, the Jameson Aerial Buddy cable sheave self-levels to a 20° angle – strapping is optional! Constructed of a Chemical, Corrosion, and UV resistant polymer that has been electrically insulated, the reinforced frame and wheel offer longer life, reduce installation fatigue and weighs 40% less than the lightest aluminum aerial sheaves. The Cable Guard ensures cables, pull tapes and pulling grips pass through the sheave easily without derailing; the spring-loaded retracting design allows for fast, simple loading or unloading of fiber optics. ALSO Available in an 8" model for straight pulls, or 24" model for set-up, take-down & turns, the Aerial Buddy delivers maximum maneuverability and unrestricted mounting options with lift hoists that swivel and rotate up to 360°. Overhead cable placing is even easier with the addition of optional slip hook and safety shackle accessories.

Jameson SHV-24 Includes: 1 Jameson Aerial Buddy 24" Polymer Sheave -Yellow

Our Price: $742.93


1 2
