Ground Hog Earth Drill Anchor Cranker
Sort By:
1
Ground Hog C-71-5H Hydraulic Earth Drill Ground Hog C-71-5H Earth Drill w/Air Filter

The C-71-5H Earth Drill is the workhorse of the Ground Hog line, tried and tested for over 30 years. Also known as an " Anchor Drill". This is a two-man drill. Auger Bits sold separately.

The Ground Hog C-71-5 is two-man earth drill designed to deliver years of reliable service with superior performance. It has been a proven performer for over 40 years. It’s rugged design promotes durability and requires very little maintenance. The heart of this unit is our time-tested transmission. The transmission is an efficient worm drive design utilizing alloy steel shafts, large, tapered roller bearings and our standard 7/8” square auger drive.


Aluminum castings are used throughout the C-71-5's construction to produce a unit that is both strong and lightweight. The C-71-5 uses an air-cooled centrifugal clutch and a trigger-type, return-style throttle. Both operator positions are equipped with individual stop switches and tubular steel handlebars.

Please note: This drill will not drive anchors without pre-drilling a pilot hole. To drill a pilot hole, we highly recommend using the following auger extensions and auger: Qty 2
MANTA LB-9054 & Qty 1 MANTA LB-4SSC 50102.

Our Price: $2,410.36
Ground Hog PSD18 Standard 18" X 3' Auger for Earth Drill Ground Hog PSD18 Standard 18" X 3' Auger for Earth Drill

The Ground Hog SD12 Standard Auger has a standard-style digging head for loose/sandy soil condition. This 12" Auger uses a screw-in fishtail centered pilot and bolt-on wide flat, hardfaced, standard side blades. All Ground Hog Augers are approximately
38"(3') in length and utilize a 7/8" standard square drive for interchangeability between Earth Drills.
Feature:

  • Part #100 Fishtail Pilot(1)
  • Part #912 Side Blade Installed(1)
  • Part #1300 Attachment Pin & Clips(1)
  • 7//8" Square Drive for interchangeability
  • Durable Powder-Coated Finished
  • 12" hole diameter

Our Price: $576.79
Ground Hog PSD12 Pengo-Style 12" X 3' Auger for Earth Drill Ground Hog PSD12 Pengo-Style 12" X 3' Auger for Earth Drill

The Ground Hog 12-inch auger with Standard style digging head. For loose/sandy soil conditions. Uses a screw-in fishtail center pilot and hardfaced bolt-on Standard style side blade. Comes ready to dig with one Part# 100 Fishtail Pilot and one Part# 912 side blade installed. Includes one Part# 1300 attachment pin and clip.
Features:

  • Part # SB-25 Pilot Bit(1)
  • Part # 35 Side Blades Installed(2)
  • Part # 1300 Attachment Pin & Chip
  • 12" hole diameter
  • 7//8" Square Drive for interchangeability
  • Screw-in hardfaced alloy steel pilot bit
  • Durable Powder-Coated Finish
  • Replaceable Forged Steel Side Blades

Our Price: $394.64
Ground Hog SD12 Standard 12" X 3' Auger for Earth Drill Ground Hog SD12 Standard 12" X 3' Auger for Earth Drill

The Ground Hog SD12 Standard Auger has a standard-style digging head for loose/sandy soil condition. This 12" Auger uses a screw-in fishtail centered pilot and bolt-on wide flat, hardfaced, standard side blades. All Ground Hog Augers are approximately
38"(3') in length and utilize a 7/8" standard square drive for interchangeability between Earth Drills.
Feature:

  • Part #100 Fishtail Pilot(1)
  • Part #912 Side Blade Installed(1)
  • Part #1300 Attachment Pin & Clips(1)
  • 7//8" Square Drive for interchangeability
  • Durable Powder-Coated Finished
  • 12" hole diameter

Our Price: $382.50
Ground Hog PSD8 Pengo-Style 8" X 3' Auger for Earth Drill Ground Hog PSD8 Pengo-Style 8" X 3' Auger for Earth Drill

The Ground Hog PSD8 Pengo 8" Auger features heat treated cast alloy steel boring heads with hardened forged steel side blades and a bolt-on cast alloy steel centered pilot bit. The Pengo Series augers are general purpose augers and are the best choice for tough soil conditions. All Ground Hog Augers are approximately 38"(3') in length and utilize a 7/8" standard square drive for interchangeability between Earth Drills.
Features:

  • Part # SB-25 Pilot Bit(1)
  • Part # 35 Side Blades Installed(2)
  • Part # 1300 Attachment Pin & Chip
  • 8" hole diameter
  • 7//8" Square Drive for interchangeability
  • Screw-in hardfaced alloy steel pilot bit
  • Durable Powder-Coated Finish
  • Replaceable Forged Steel Side Blades

Our Price: $321.79
Ground Hog SD4 Standard 4" X 3' Auger for Earth Drill Ground Hog SD4 Standard 4" X 3' Auger for Earth Drill

Ground Hog Pengo Drill 4" x 3'. Ground Hog offers a large range of augers and accessories for our earthdrills to cover all types of soil conditions and customer requirements. We have augers in three different styles available from 2" to 12" in diameter for our C-71-5 Two-Man, 1M5C One-Man and HD99 Hydraulic earthdrills as well as 14", 16" and 18" Pengo style nursery/planting augers for use with the HD99. Anchor Cranker, Earth Auger, Ground Hog

Our Price: $188.24
Ground Hog SD2 Standard 2" X 3' Auger for Earth Drill Ground Hog SD2 Standard 2" X 3' Auger for Earth Drill

Ground Hog offers a large range of augers and accessories for our earthdrills to cover all types of soil conditions and customer requirements. We have augers in three different styles available from 2" to 12" in diameter for our C-71-5 Two-Man, 1M5C One-Man and HD99 Hydraulic earthdrills as well as 14", 16" and 18" Pengo style nursery/planting augers for use with the HD99. Anchor Cranker, Earth Auger, Ground Hog
Ground Hog Pengo Drill 2" x 3' GROU-SD2

Our Price: $151.79
Ground Hog SB 25CXC Full Carbide-Tipped Pilot Bit Ground Hog SB 25CXC Full Carbide-Tipped Pilot Bit

The SB-25cxc is a full carbide version of the SB-25 Pengo style pilot bit. There are peices of carbide on the tips and down the sides of this bit for greater wear resistance. This pilot will fit all of our Pengo style augers except for the PSD4. Includes the nut and bolt for mounting to the auger.
Note: Does not fit the PSD4 auger.

Our Price: $124.67
MANTA LB-30322 Little Beaver Utility Anchor Adaptor (Fits into #30272) MANTA LB-30322 Little Beaver Utility Anchor Adaptor (Fits into #30272)

Driving utility anchors is made easier with this special adaptor. With Little Beaver’s anchor handle, hydraulic earth drill and torque tube, one-man installation of utility anchors is now possible. (60 RPM only)

Our Price: $116.51
Ground Hog EX3  3' Auger Extension Ground Hog EX3 3' Auger Extension

Auger Extension 3' GROU-EX3
Ground Hog offers a large range of augers and accessories for our earthdrills to cover all types of soil conditions and customer requirements. We have augers in three different styles available from 2" to 12" in diameter for our C-71-5 Two-Man, 1M5C One-Man and HD99 Hydraulic earthdrills as well as 14", 16" and 18" Pengo style nursery/planting augers for use with the HD99. Anchor Cranker, Earth Auger, Ground Hog

Our Price: $72.86
Ground Hog EX2 - 2' Auger Extension Ground Hog EX2 Auger Extension 2'

Auger Extension 2' GROU-EX2
Ground Hog offers a large range of augers and accessories for our earthdrills to cover all types of soil conditions and customer requirements. We have augers in three different styles available from 2" to 12" in diameter for our C-71-5 Two-Man, 1M5C One-Man and HD99 Hydraulic earthdrills as well as 14", 16" and 18" Pengo style nursery/planting augers for use with the HD99. Anchor Cranker, Earth Auger, Ground Hog

Our Price: $62.33
Ground Hog EX1 - 1' Auger Extension Ground Hog EX1 Auger Extension 1'

Auger Extension 1' GROU-EX1
Ground Hog offers a large range of augers and accessories for our earthdrills to cover all types of soil conditions and customer requirements. We have augers in three different styles available from 2" to 12" in diameter for our C-71-5 Two-Man, 1M5C One-Man and HD99 Hydraulic earthdrills as well as 14", 16" and 18" Pengo style nursery/planting augers for use with the HD99. Anchor Cranker, Earth Auger, Ground Hog

Our Price: $60.71
Ground Hog SB 25C Carbide-Tipped Pilot Bit Ground Hog SB 25C Carbide-Tipped Pilot Bit

The SB-25c is a carbide-tipped version of the SB-25 Pengo style pilot bit. There are two peices of carbide on the very tips of this bit for greater wear resistance. This pilot will fit all of our Pengo style augers except for the PSD4. Includes the nut and bolt for mounting to the auger.
Note: Does not fit the PSD4 auger.

Our Price: $58.50
