Bronze Ground Rod Clamps, used with copperbonded 1/2" ground rods, provide a low resistance, secure copper-to-coppe...

• Provides a permanent connection between a copper water pipe or power service mast and a #14 to #10 AWG ground wire.

• Strap is equipped with an integral square nut which has a male engagement projection that works as a guide during assembly. Strap is supplied with a wire washer and hex nut/hex screw.

• Hardware is sized for installation with a standard 3/8" - 7/16" Can Wrench.

• Hardware is manufactured from pure brass.

• Copper Ground Straps are manufactured from dead soft Copper.

• Stock size is 1/2" x .020".

• UL Listed.

3M Scotchlok 4462SN Shield Bond Connectors
This 3M Scotchlok Shield Bond Connector is specifically designed to supply greater pullout strength than the 4462 shield bond connector. The nuts have been deepened, too, making them much easier to hold and tighten.The shield bond connector is also designed for use with coated cables and has superior electrical properties for the protection of data circuits.

NVENT ERICO EHL58C1K 5/8" Ground Rod Connector Hammer Lock Copper

These ground rod connectors help to connect grounding conductors to ground rods. They are machined from highly conductive copper to provide a low-resistance connection and to withstand ground fault currents and lightning transients.

• Provides a permanent connection between a copper water pipe or power service mast and a #14 to #10 AWG ground wire.
• Strap is equipped with an integral bracket. Bracket is used for engaging screw and opposite end of strap.
• Hardware is sized for installation with a standard 3/8" - 7/16" Can Wrench.
• Hardware is manufactured from pure brass.
• Copper Ground Straps are manufactured from dead soft Copper.
• Stock size is 1/2" x .020".
• Ground Straps are protected by U.S. Patent 6,398,596.

BRONZE BONDING CLAMP


• Used to bond #6 copper wire to 1/4" or 5/16" strand
• Constructed of high strength copper alloy
• Installation does not require removal of bolt
• Semi tin plated with one bare bronze groove for copper to copper bond and other groove to be used with dissimilar metals
• Installs with standard terminal wrench

ALUMINUM GROUNDING LUG

• Used to mechanically bond ground wire to equipment.
• One hole on front of connector for attaching ground wire.
• Accepts ground wire ranging from #14 - #4 AWG
• Mounting hole accommodates 1/4" stud.
• Body constructed from high strength Aluminum.
• Set screw is installed with a flat head screwdriver.

This grounding clamp is used to bond the cable sheath to the messenger strand. Clamp body is made with an inside keeper riding on the end of the bolt. 1/2" bolt can be removed to place the clamp over the messenger wire.

MSI SI-2181 Beam Clamp w/ Square Head, is used to provide an electrical connection to trailers, mobile homes or other beam structures. The cup point on bolt penetrates through surface paint or oxide for intimate ground to base metal.
Specifications:

• Seperate screws to attach #14 to #6 AWG ground wires
• High strength bronze casting
• UL & CUL Listed
• Bolt Head: Square
• Beam Ground Clamp


  Structure Ground Clamp

The semi-Tin plated Bronze Bonding Clamp assembly consists of two clamp sections and a 5/16 x 7/8-inch bronze hex washer head bolt.
One clamp section is tapped to allow installation with a single wrench.

MSI H-BVC-6 Bronze Vise Connector

• Interlocking components ensure a long term, vibration proof connection, one Piece, side opening design eliminates loose parts, cross threading, and eases installation on run conductor
• Easy to install with gloves or hot sticks
• Connectors can be installed on structures, cabinets and enclosures
• Conductor Range AWG: Max. #6 STR Min. #10 SOL
• Bolt Thread Size: 1/4"
• Bolt Hex. Size: 3/8"

Used to provide a solderless connection between ground wires.

• Vise-type connectors made of corrosion resistant, high strength bronze
• Fast, easy installation
• Vibration proof connection
• Connector Diameter Range 8 sol- 1/0 str
• Bolt Thread Size 5/16
• Hex Head 9/16

Thomas & Betts C-Taps Connector for 600v Applications 2/0 AWG TO 250 KCMIL RUN, 8 TO 4/0 AWG TAP, PLAIN WROT COPPER, C SHAPE,

• I deal for pigtailing, Two-way splicing or tapping to an unbroken continuous main

• Heavy reinforcing ribs help locate compression dies and strengthen compressed joint

• Dims: L 1-11/16, H 31/32, E 23/64

• Color Key: Orange

Coppercoated staples are used to secure Bare ground wire to wood poles.

Coppercoated staples are used to secure Bare ground wire to wood poles.

Ground rods are driven vertically into the ground and bonded together with bare copper wire for electrical grounding.

" Must Ship LTL Freight"

-Due to the 10 ft length, this must ship LTL Freight.
-Due to limited shipping cost calculations, when ordering several of these please call for accurate freight cost.

• Ground rods are driven vertically into the ground and bonded together with bare copper wire for electrical grounding.

A 3/4" X 10' Copper Bonded Steel Ground Rod. All Blackburn ground rods have
a heavy uniform covering of electrolytic copper bonded to a rigid steel core.
Copper ions are forced electrically to join with the steel core, establishing a
corrosion-resistant bond between the copper and the steel.

" Must Ship LTL Freight"

-Due to the 10 ft length, this must ship LTL Freight.
-Due to limited shipping cost calculations, when ordering several of these please call for accurate freight cost.

A 3/4" X 12' Copper Bonded Steel Ground Rod. All Blackburn ground rods have
a heavy uniform covering of electrolytic copper bonded to a rigid steel core.
Copper ions are forced electrically to join with the steel core, establishing a
corrosion-resistant bond between the copper and the steel..

" Must Ship LTL Freight"

-Due to the 10 ft length, this must ship LTL Freight.
-Due to limited shipping cost calculations, when ordering several of these please call for accurate freight cost.

NVENT ERICO EDS58 Drive Sleeve, Grounding, 5/8 in Rod Dia.

This grounding drive sleeve features copper-coated steel construction. It slides on the top of ground rods to prevent mushrooming.

• ITEM Drive Sleeve
• TYPE Grounding
• MATERIAL Copper Coated Steel
• ROD DIA (IN) 5/8"
• CONDUCTOR SIZE (AWG) #8 Sol to #2 Str.

1-1/4 x 5/16 x .120 Galvanized Rolled Diamond Point Staples for Coated Ground Wire

• Used to secure Coated ground wire and molding to telephone poles.
• Hot dip galvanized to meet ASTM Specification A153.
• Diamond Point Ground Wire Regular

2" X 5/8" X .162" ROLLED POINT GALVANIZED STAPLE

• Used to secure ground wire and molding to telephone poles.
• Hot dip galvanized to meet ASTM Specification A153.
• Use with H-PM128-GRAY Plastic Molding

Galvanized staples are used to secure Wooden molding to wood poles.

H-J1163 Ground/Bond 5/8"

• Used to attach ground wires at the nut end of bolts on transmission lines
• Includes two 1½" long clamp sections and one square nut
• Constructed of high quality steel, hot-dip galvanized
• Ground Wire Diameter 3/16" - 3/8"

These ground rod clamps have a 7/16" U-bolt and a drop forged clamping piece.

Bronze ground rod clamp, used with copper - bonded ground rods, provide a low resistance, secure copper to copper connection.

Bronze Ground Rod Clamps, used with copperbonded 3/4" ground rods, provide a low resistance, secure copper-to-copper connection. These heavy-duty clamps develop a high-pressure contact between the rod and the grounding wire and can be easily disconnected when it is desired to measure resistance of the ground.

Sliding hammer type ground rod driver provides maximum operator safety and driving force. This driver works on rods up to 3/4" diameter. Heavy rubber handgrips absorb the shock of high-density substrate materials. Made of steel and finished with a durable powder coat. Wt. 33 lbs. H693, H-693 LEMCO
There is No Warranty on the Ground Rod Driver Lemco H-693 as this is a hammer tool and it may wear out quickly depending on the soil conditions.

Ground Rod Pounder

#6 guage poly ASTMB3 coated solid copper wire 500 ft. Priced per roll. Black coating

Soft # 6 bare copper wire 315 ft
Priced per roll

Used for ground wire insulation.
Material: Wood
Length: 8 feet Bundle of six Sticks.

Galvanized staples are used to secure ground wire and ground wire molding to wood poles.

Galvanized staples are used to secure ground wire and ground wire molding to wood poles.

Galvanized staples are used to secure ground wire and ground wire molding to wood poles.

Grounding Clamp, Copper Cable to Cable, Vice Type. 6 Gage & 6-14 Gage conductors
For copper connections-Splice, Loop deadend or service entrance tap or grounding connections • One piece design for easier, faster installation • Bolt head design for use with standard ratchet wrench • Vise design achieves high connector pressure with low wrench force

MSI SI-2168C(meter box clamp) Clamp
Connector: Bonding Corner for Metter Box and Wire.

J hooks are used for supporting bail-type drop wire and deadend clamps from poles and crossarms.

Screw Ground Rod provides a temporary ground where a system ground is not available. When installed, the 6' spiraled ground rod develops less resistance than straight ground rods. Actual effectiveness depends upon soil properties. The reusable Ground Rod is copper clad. The helix (spiral), handle and wing nut are bronze.

• Larger Split Bolt
• Used to make a bonding connection between two copper ground wires.

• Bolt and nut formed from high-strength corrosion resistant C210 Copper.

• Specially designed pressure bar provides high pull-out strength.

• Under torque, provides high contact pressure between ground wires.

• Smallest two conductors accepted: 6 Sol.

• Largest two conductors accepted: 2 Str.

• Min. wire size that can be used with Max. wire size: 14 Str.

• Tested and UL listed to UL486A requirements.

• Used to make a bonding connection between two copper ground wires.

• Bolt and nut formed from high-strength corrosion resistant C210 Copper.

• Specially designed pressure bar provides high pull-out strength.

• Under torque, provides high contact pressure between ground wires.

• Smallest two conductors accepted: 8 Sol.

• Largest two conductors accepted: 4 Sol.

• Min. wire size that can be used with Max. wire size: 16 Sol.

• Tested and UL listed to UL486A requirements.

H-854 /SI-2006 SPLIT BOLT
Allied Bolt Part # 854

• Used to make a bonding connection between two copper ground wires.
• Bolt and nut formed from high-strength corrosion resistant C210 Copper.
• Specially designed pressure bar provides high pull-out strength.
• Under torque, provides high contact pressure between ground wires.
• Smallest two conductors accepted: 10 Sol.
• Largest two conductors accepted: 6 Sol.
• Min. wire size that can be used with Max. wire size: 16 Sol.
• Tested and UL listed to UL486A requirements.

• Used to make an electrical connection between ground wire and messenger or guy strands
• Up to 2/0 AWG ground wire
• Up to 7/16" strand size
• Constructed of aluminum

Positive, all-around compression with low resistance and high pull-out values. Ideal for pigtailing, 2-way splicing or tapping to an unbroken continuous main. Heavy reinforcing ribs help locate compression dies and strengthen compressed joint.

• I deal for pigtailing, Two-way splicing or tapping to an unbroken continuous main

• Heavy reinforcing ribs help locate compression dies and strengthen compressed joint

• Dims: L 1-11/16, H 7/8, E 21/64

• Color Key: Black

The 54740TP is positive, all-around compression with low resistance and high pull-out values. Ideal for pigtailing, 2-way splicing or tapping to an unbroken continuous main.

• I deal for pigtailing, Two-way splicing or tapping to an unbroken continuous main

• Heavy reinforcing ribs help locate compression dies and strengthen compressed joint

• Dims: L 1-11/16, H 31/32, E 23/64

• Color Key: Orange

BURNDY Compression C Tap Thin Wall - Purple H YC26L12
Made of high-conductivity wrought copper, the connector's heavy reinforcing ribs locate the compression dies and strengthen the compression joint. These connectors assure positive, all-around compression with low resistance and high pullout values. Units are UL-approved for direct burial. For 600V applications.
T&B Thomas & Betts T N B C-Tap Crimps

The TBM5-S comes with five multi-nested color-coded die sets, which mount directly on the tool for storage and whose codes are automatically embossed on the crimped connector. Features Shure-Stake ratchet.

Thomas and Betts makes the TBM5S color-keyed mechanical compression tool for C-Taps, Copper and Aluminum connectors.

• Wide range of #8 AWG to 250 kcmil for copper and # 10 to 4/0 AWG for aluminum lugs and splices
• Also installs C-taps from 54705 to 54705
• Shure-Stake Mechanism ensure a property complete crimping each time
• Includes color-code-embossed installation dies

Applications.

• I deal for pigtailing, Two-way splicing or tapping to an unbroken continuous main

• Heavy reinforcing ribs help locate compression dies and strengthen compressed joint

• Dims: L 1-5/32, H 27/32, E 9/32

• Color Key: Pink

The Tiiger ground rod driver eliminates the need to climb above the rod for installation.
Designed with a positioning guide pin which allows the driver socket of the impact tool to
be engaged to the ground rod driver.

The Tiiger ground rod driver eliminates the need to climb above the rod for installation. Designed with a positioning guide pin which allows the driver socket of the impact tool to be engaged to the ground rod driver.

For connecting ribbon or braid to ribbon, braid or bus.
Side Opening Jaw facilitates easy installation.

Silicon bronze clamps adjustable by single hex head screws, used to connect various size grounding conductors, as well as pole line apparatus to grounding conductors. Features.Casting and bolt are both made of silicon bronze for greater strength, conductivity, and corrosion resistance. Install using the standard can wrench. EM 2370 Manufactured to Bell Spec CA08980 (H1). It accommodates: •Single or multiple #6 AWG wires solid or stranded. •#6 AWG to #10 or #12 AWG. •From single 2-pair BSW metallic shield, to three 2-pair BSW metallic shields.

Silicon bronze clamps adjustable by single hex head screws, used to connect various size grounding conductors, as well as pole line apparatus to grounding conductors.
Features.Casting and bolt are both made of silicon bronze for greater strength, conductivity, and corrosion resistance. Install using the standard can wrench.

H2 silicon bronze clamp.

Accommodates:

•#12–#4 AWG solid.
•1/0 B, C, or D stranded copper to #6, #8, #10, #12 AWG solid bare copper wire.
•6.6–10M support strand to #6, #8, #10, #12 AWG solid bare copper wire.
Add suffix -T for a tin-plated clamp.

Silicon bronze clamps adjustable by single hex head screws, used to connect various size grounding conductors, as well as pole line apparatus to grounding conductors. Features.Casting and bolt are both made of silicon bronze for greater strength, conductivity, and corrosion resistance. Install using the standard can wrench. EM 0167 Tin-plated bronze C connector with teeth for piercing the messenger insulation of Figure 8 cable. For messenger diameters of .146"–.312" (3.71–7.94mm) and ground conductor range of .146"–.312". Available with stainless steel or bronze bolt.
