Turnbuckles are used as adjustable extension links to maintain proper tower clearance on assemblies at tower end.
• 320595-I • Jaw-Eye Turnbuckles .
• Size - 3/4'' • Take Up - 12'' • Heavy duty.
• Break Strength Lbs. - 26,000.
• Hot-dip galvanized
• Meets Federal Specification FF-T-791B, Type1, Form 1, Class 7.

Turnbuckles are used as adjustable extension links to maintain proper tower clearance on assemblies at tower end.
• 320598-I • Jaw-Jaw Turnbuckles .
• Size - 3/4'' • Take Up - 12'' • Heavy duty.
• Breaking Strength - 26,000 Lbs.
• Hot-dip galvanized
• Meets Federal Specification FF-T-791B, Type1, Form 1, Class 7.

Turnbuckles are used as adjustable extension links to maintain proper tower clearance on assemblies at tower end.
• 320598-I • Jaw-Jaw Turnbuckles .
• Size - 3/4'' • Take Up - 18'' • Heavy duty.
• Breaking Strength - 26,000 Lbs.
• Hot-dip galvanized
• Meets Federal Specification FF-T-791B, Type1, Form 1, Class 7.

Turnbuckles are used as adjustable extension links to maintain proper tower clearance on assemblies at tower end.
• 320597-I • Jaw-Eye Turnbuckles .
• Size - 5/8'' • Take Up - 12'' • Heavy duty.
• Break Strength Lbs. - 17,500.
• Hot-dip galvanized
• Meets Federal Specification FF-T-791B, Type1, Form 1, Class 7.

Turnbuckles are used as adjustable extension links to maintain proper tower clearance on assemblies at tower end.
• 320598-I • Jaw-Jaw Turnbuckles .
• Size - 5/8'' • Take Up - 12'' • Heavy duty.
• Breaking Strength - 26,000 Lbs.
• Hot-dip galvanized
• Meets Federal Specification FF-T-791B, Type1, Form 1, Class 7.

Guy Strain Insulator is intended for use with down guys or pole-to-pole guys on overhead lines.

• Strength 30,000lbs.
• End Fitting Clevis to Thimble Eye

Guy Strain Insulator is intended for use with down guys or pole-to-pole guys on overhead lines.

• Strength 30,000lbs.
• End Fitting Clevis w/Roller to Clevis w/Roller

Guy Strain Insulator is intended for use with down guys or pole-to-pole guys on overhead lines.

• Strength 30,000lbs.
• End Fitting Clevis w/Roller to Thimble Eye

Guy Strain Insulator is intended for use with down guys or pole-to-pole guys on overhead lines.

• Strength 30,000lbs.
• End Fitting Thimble Eye to Thimble Eye

H-J151 Isulator Spool

Type: Wet process, 3x3 11/16 hole for 5/8 Pin 1/8" thick, Porcelain -- Fits Hub 0340 Clevis and Pin.

*In the picture the H-J151 Insulator Spool is pictured on the right*
(The Hubbell 0340 Insulated Clevis is pictured on left - sold separately)

HUB-0340 Insulated Clevis

Standard, Material: Steel, Clevis Type.11/16 Mount Hole Clevis Pin Diameter: 5/8 IN, Clevis Size: 5 IN Length X 1-1/2 IN Width X 3-5/16 IN Height, Finish: ASTM A-153 Galvanized, Mounting: 11/16 X 3/4 IN Oval, Material Size: 3/16 IN X 1-1/2 IN, Standards: ANSI C135.20

*In the picture the Hubbell 0340 Insulated Clevis is pictured on the left* .
(The H-J151 Insulator Spool is pictured on right - sold separately)

The insulator support angle mounts at the ends of a double arm and acts as a fastening point for suspension or pin-type insulators.

• HOT DIP GALVANIZED
• Manufactured from 2-1/2 x 2-1/2 x 1/4-inch steel angle
• All holes accommodate 5/8-inch bolts

Height 3 1/2" , Width 2 1/2", Max Cable Size: 3/8"
Porcelain Guy Strain Insulator, use preforms to attach to strand to make down guy non-conductive.

Height 4 1/2" , Width 2 7/8", Max Cable Size: 1/2"
Porcelain Guy Strain Insulator, use preforms to attach to strand to make down guy non-conductive.

Height 5 1/2" , Width3 3/8", Max Cable Size: 5/8" Porcelain Guy Strain Insulator, use preforms to attach to strand to make down guy non-conductive.

MAST CLAMP WIRE HOLDERS Holds incoming service entrance cables Material: Porcelain Wire Holder, Adjustable Galvanized Steel Clamp. Madison P-18 1-1/4" -3 Mast Clamp Wire Holder, Porcelain Wire Holder WAL 610.

The PLP Elastomeric tie tube is designed to minimize abrasion to bare conductors and insulators.

• Used for accepting drop wire on houses.
• The Type S Porcelain Knob is used in conjunction with a H-373 5/16" Angle Screw for securing a single drop wire to the side of a building.

Single Upset Spool Bolt 5/8" X 14" MP J2348-1/2 Minimum TENSILE STRENGTH 13,550 LBS
H-J2348-1/2 Single Upset Spool Bolt

• Shank Length: 14"
• Overall Length: 18-1/2"
• Thread Length: 6"
• Used for side-of-pole installation when supporting neutral conductors and secondary service wires
• Forged with either a single or double integral washer upset at insulator end
• Double upset provide 15⁄8" clearance between insulator and pole
• Spool bolts have 5⁄8" rolled threads
• Constructed of high quality steel, hot-dip galvanized
• Use With H- J151 spool type insulator.
