CADDY PYRAMID ROOFTOP SUPPORT SYSTEM WAL-CAD-PSF-10C
Used to support conduit on Roofs.

• Provides superior support for pipe, conduit, duct, cable tray and equipment
• Foam bottom offers low abrasion interface for better roof membrane protection
• Compatible with roof surfaces including single ply, bituminous, metal and spray foam
• Provides superior load distribution, even with varying rooftop surfaces
• Ready to use out of the box, saving installation time and labor
• Multiple sizes and load ratings offer the ability to tailor the solution to the application
• Easy to transport to the roof
• Hot-dip galvanized and UV stabilized for long lasting performance
• Supports green building requirements; thermoplastic bases are made from recycled material and can contribute to earning LEED credits

SPECIFICATIONS

SOLD ONE EA.

The L.H. Dottie FW10 Flat Washer is round with a 7/32-inch inner
diameter, an 1/2-inch outer diameter and a 3/64-inch thickness.
Fits a #10 bolt fastener size. Made of steel, Zinc plated finish.
sold as 100 pack.

Hanger Bolt, Plain Center, 3/8-Inch diameter by 3-Inch length size, Steel material.

The L.H. Dottie RC2 Rod Coupling is a straight rod coupling used
to couple threaded rod for extended lengths. Size: 3/8-inch diameter
by 1-1/8-inch length. Made of steel. Zinc plated finish.

PS-1100-AS-1-EG, 1" Pre-assembled electrogalvanized steel clamp, for 2" conduit. Fits rigid and sch40/80 pipe.
Power-Strut PS-1100-AS-1-EG RIGID PIPE Steel Clamp 1"

All Threaded Rod 3/4 inches X 10 feet, electroplated allthread rod.

All Threaded Rod 3/4 inches X 10 feet,hot dipped galvanized.

PS-1100-AS-2-EG, 2" Pre-assembled electrogalvanized steel clamp, for 2" conduit. Fits rigid and sch40/80 pipe

PS-1100-AS-3-EG, 3" Pre-assembled electrogalvanized steel clamp, for use with Rigid, SCH40/80 conduit.

PS-1100-AS-4-EG, 4" Pre-assembled electrogalvanized steel clamp, for use with 4" conduit.Fits rigid and sch40/80 pipe

PS-1100-AS-6-EG, 6" Pre-assembled electrogalvanized steel clamp, for use with 6" conduit.Fits rigid and sch40/80 pipe.

Power-Strut Continuous thread rod in electro-galvanized finish is made of steel that offers strength and durability.
It measures 3/8 Inch diameter x 10 ft.
Sold Per Foot.

All Thread Rod 5/8 inches X 10 feet,hot dipped galvanized.

Power-Strut Continuous thread rod in electro-galvanized finish is made of steel that offers strength and durability.
It measures 5/8 Inch diameter x 10 ft.
sold per 10' stick

Steel Spring Nut with long spring, 3/8" thread diameter, with electro-galvanized finish.
For use with PS 200,210, and 300.

Tap Bolt, Full thread, 3/8-Inch-16 TPI by 1-Inch length size, 9/16-Inch Hex,
Grade 2 Low Carbon Steel material, Zinc plated finish.

• Constructed of high quality steel, hot-dip galvanized
• 1-3/8" DIA. 9/16 HOLE
• can be used with J8245 drop hook for wood crossarms

• 1000 PER CARTON


ROUND WASHER 2" DIA. 13/16 HOLE H-J1089. Galvanized for 3/4" Bolts

• Constructed of high quality steel, hot-dip galvanized
