Cable Sheath Slitter GMP-10923
Works with cable from 1/2" to 4". Ratchet design is safer for both user & cable compared to sheath knives. Also effective on innerduct. The slitter comes with a plastic case and includes stripper tool, 1 replacement blade, Allen wrench & plastic shim for small diameter cable.
Cable Stripper/Slitter Condux 08013000
CONDUX offers two sizer of the Stripper/Slitter for easy and rapid preparation of round cables from .18 (5mm) up to 1.42"(36mm) in diameter and 8 AWG up to 500kcmil.
Figure 8 Jacket Slitter GMP 82720
OBSOLETE
GMP 82720 Figure 8 Jacket Slitter
The smooth, plane-like shaving action of this simple tool lets you quickly remove the polyethylene covering from the jacketed messenger on figure-8 cable without hitting the strand or damaging the cable
- The tool's wooden handle has a metal cutting guide and steel blade at one end
- the guide's special design assures that you'll cut to the correct depth every time
- Replacing the hardened steel blade is just as easy: release two screws in the quide, change blades, and re-tighten the screws
- Replacement Blade Part # 82721
Figure 8 Web Slitter GMP 82730
You can use this plier-type tool to slit the web between the strand and cable core on figure 8 cable and Aerial Duct. Model B Web Slitter for .250 in. (Also referred to as a 305B tool) (6.4mm) messenger dia.
- All you have to do is hold the block of the slitter parallel to the strand and draw it along the cable and strand
- This self-guiding tool makes sure the blade pierces the web and not the sheath or strand jacket
- The cutting blade is held with one screw and reinforced with a square washer to prevent bending
- The tool is zinc plated to resist corrosion
Figure-8 Aerial Self-Supporting Duct Slitters RIPLEY 80260
RIPLEY 305 WEB-B Ideal messenger removal & jacket slitting tools for round, figure-8 aerial ducts, Tension-spring design closes tool to increase safety & prevent injury, Handles feature yellow, plastic-coated grips for greater leverage, Tool heads match messenger sizes, MJ & MW models have a locking latch to make slitting easier, Blades are replaceable.
Replacement Blade
Innerduct Cutter 3/8'' - 3 1/2'' GMP 10912
Innerduct Cutter for 3/8'' - 3 1/2''
Used primarily for allowing access to fiber already placed inside of inner duct when it needs to be repaired, or broken out, the tubing cutters provide a lean cut every time.
Innerduct Slitter Condux 08012925
Mechanical Innerduct Slitter is designed to reduce the effort required to longitudinally slit long sections of both High Density Polyethylene (HDPE) and Medium Density Polyethylene (MDPE) innerduct and conduit that have an outside diameter ranging from 11⁄4" (32 mm) to 2" (51 mm)
Condux Innerduct Slitter 08012925
Innerduct Slitter Condux 08013100
The Innerduct Slitter is designed for fast, safe cutting of innerducts from 1" (25 mm) to 2" (51 mm). HDPE Slitter.1.25"-2.0"Range.
Innerduct Slitter REPLACEMENT BLADES Condux 08013101
Replacement blades for the TurboSlitter™ from Condux, a cordless drill attachment that can easily split HDPE pipe with wall thicknesses ranging from 0.097 to 0.216 inches! The cordless drill attachment quickly adjusts to fit almost any rechargeable drill, 14-volt and larger. Save time and effort on the job with the TurboSlitter from Condux.
Condux Innerduct Slitter REPLACEMENT BLADES for 08013101
JONARD AST-200 Cable Saber™ - Armored Mid-Span Cable Slit & Ring Tool (4 - 28.6 mm)
The Jonard CableSaber™ is the ultimate tool for gaining mid-span access to armored or thick jacketed cables 4 mm-28.6 mm (0.157”-1.125”) in diameter.
This mid-span cable slit and ring tool also features the following:
- Adjustable blade depth up to 5.5 mm (0.216”)
- Precision steel blade will cut through the toughest materials
- Blade can be set to be longitudinal for slitting or radial for ringing
- For use on cables 4 mm-28.6 mm (0.157”-1.125”) in diameter
- Aluminum shaft provides tremendous stability while slitting or ringing, preventing spiraling from occurring
- Shaft housing acts as a handle, providing greater leverage while slitting for convenience while ringing
- Thumb screw allows blade depth to be adjusted quickly by hand
- Rugged anodized aluminum and steel construction for maximum durability
List Price: $142.95
Our Price: $113.80
You save $29.15!
JONARD AST-RB Replacement Blade AST-10 & AST-118 (2 Per Pkg)
This is a two pack of replacement blades for the AST-10, AST-118, and AST-200 Armored Mid Span Cable Slitting Tools.
These blades feature the following:
- Precision steel blade will cut through the toughest materials and ensure no damage to the internal fibers
- Suitable for both slitting and ringing applications
List Price: $49.95
Our Price: $39.87
You save $10.08!
JONARD FOD-2000 Fiber Optic Drop Cable Slitter
The Jonard Tools PATENTED and award-winning FOD-2000 Fiber Optic Drop Cable Slitter simplifies the slitting of drop cable jackets at mid span or end sections and is perfect for FTTH technicians working with flat fiber drop cables.
This drop cable slitter features the following:
- Designed to slit 0.250” flat drop cables as well as various other cables such as Super Essex Communications Series 6U, 6T tonable, W7, W7 tonable, 6U 24F, and 6T 24F tonable flat drop cables
- Slits flat cables 0.305" to 0.350" wide and 0.155" to 0.185" high, typically found in Corning SST-Drop flat cables with a jacket thickness of 0.03” to 0.04”
- Slits both sides of the jacket simultaneously, allowing easy access to fiber or strength members
- Can separate the jacket and strength members from the buffer tube leaving fiber undamaged
- Two reversible blades come preassembled and can be reversed when worn for double life
- Replacement Blades (FOD-RB25) can be purchased separately
- NSPE New Product Award (See below in Downloads section)
List Price: $54.95
Our Price: $43.67
You save $11.28!
JONARD MS-6 Mid Span Slitter (1.2 mm-3.3 mm)
Designed to provide easy access to optical fibers in loose buffer tubes 1.2mm - 3.3 mm diameter. With 6 precision grooves buffer tube slitting is done without damage to the fiber. The blades are replaceable.
Groove Sizes:
1.2 - 1.5 mm1.5 - 1.8 mm1.8 - 2.1 mm2.1 - 2.5 mm2.5 - 2.9 mm2.9 - 3.3 mm
Easy to use:- Select the correct groove. Each groove is marked with the recommended fiber size
- Place the fiber in the groove to be used. The arrow on the top of the MS-6 indicates blade location and pulling direction.
- Close the tool making sure lock is engaged and pull
List Price: $72.95
Our Price: $58.33
You save $14.62!
JONARD RCS-25 Ratcheting Cable Slitter
Designed to dismantle heavy-duty cables, this ratcheting cable slitter is the perfect tool for slitting and ringing round cables greater than 25 mm in diameter.
- This cable slitter features the following:
- Fixed jaws and ratcheting feature make it easy to grip and slit heavy-duty cables
- Slits and rings cable made of PVC, PE, rubber, and other jacket materials
- Replaceable double-ended blade has an adjustable cutting depth of 0 to 5 mm (0” to 0.20”)
- Blade is made of steel plus ground and heat-treated for a razor-sharp edge and long term durability
- 10 mm, 20 mm, 30 mm ruler marked on tool for accurate and precise slitting lengths
- Perfect for mid span or end cable slitting and ringing
List Price: $155.95
Our Price: $124.67
You save $31.28!
JONARD RCS-30 Ratcheting Duct and Cable Slitter
Designed to create mid-span slits and window cuts in ducts and heavy-duty cables, this ratcheting cable slitter is the perfect tool for slitting and ringing cables or ducts greater than 25 mm in diameter.
This duct slitter features the following:
- Unique blade penetrates duct walls up to 5 mm thick, allowing you to make mid-span window cuts in cables and ducts
- Fixed jaws and ratcheting feature make it easy to grip and slit heavy-duty cable & cut into ducts at midspan
- Slits and rings cable made of PVC, PE, rubber, and other jacket materials
- Replaceable double-ended blade has an adjustable cutting depth of 0 to 5 mm (0” to 0.20”)
- 10 mm, 20 mm, 30 mm ruler marked on tool for accurate and precise slitting lengths
- Perfect for mid-span or end cable slitting and ringing
List Price: $168.95
Our Price: $135.47
You save $33.48!
JONARD RST-8514 Riser Slitting Tool
Designed to shave a longitudinal access window in round FTTH riser cables and microducts for mid-span access. This riser slitting tool is perfect for making access windows on cables 8 to 14 mm (0.33” to 0.55”) in diameter without damaging the fiber inside.
This tool features the following:
- Lightweight and narrow body can access closely spaced and surface mounted cables
- High carbon steel blade slices through any type of FTTH cable
- Factory-fixed blade requires no adjustments when working with different diameter cables
- Easily replaceable blades can be purchased separately (RST-RB25 replacement blades, pack of 25)
List Price: $96.95
Our Price: $77.87
You save $19.08!
JONARD RST-RB25 Replacement Blades for RST-8514 (Pack of 25)
This product is a replacement blade set for the RST-8514 Riser Slitting Tool. This replacement blade set includes (25) replacement blades. The blades are made of SK5 steel for high durability and long life.
List Price: $41.95
Our Price: $33.27
You save $8.68!
Replacement Blade Condux 08013001
Replacement Blade CONDUX 08013001 (fits both sizes) offers two sizer of the Stripper/Slitter for easy and rapid preparation of round cables from .18 (5mm) up to 1.42"(36mm) in diameter and 8 AWG up to 500kcmil.
Ripley MWSS 400 Messengered Web Slitter & Shaver Tool
The Ripley MWSS 400 Messenger Web Slitter & Shaver is a dual function tool designed to first remove the cable messenger by slitting the web, then shave the residual web material leaving a smooth surface on the cable jacket. Uses a CB 229 replacement slitter blade.
Ripley MWSS 500 Messengered Web Slitter & Shaver Tool
The Ripley MWSS 500 Messenger Web Slitter & Shaver is a dual function tool designed to
first remove the cable messenger by slitting the web, then shave the residual web material
leaving a smooth surface on the cable jacket. Uses a CB 209 replacement slitter blade.
Ripley MWSS 700 Messengered Web Slitter & Shaver Tool
The Ripley MWSS 700 Messenger Web Slitter & Shaver is a dual function tool designed to
first remove the cable messenger by slitting the web, then shave the residual web material
leaving a smooth surface on the cable jacket. Uses a CB 226 replacement slitter blade.
Ripley MWSS 800 Messengered Web Slitter & Shaver Tool
The Ripley MWSS 800 Messenger Web Slitter & Shaver is a dual function tool designed to first remove the cable messenger by slitting the web, then shave the residual web material leaving a smooth surface on the cable jacket. Uses a CB 228 replacement slitter blade.
Ripley US15-7001 Large Format Cable Slitter (Inch Scale)
Introducing the new US15 Large Format Cable Slitter, a versatile tool cable of performing slit, ring, and spiral cuts on cable diameters from 10 to 60 mm. Equipped with a hardened steel blade, the tool provides fast, safe, and precise jacket removal from both hard and soft insulated cables without damaging the underlying layers.
Turbo Slitter - Pneumatic Condux 08010210
The TurboSlitter™ from Condux can easily split HDPE pipe with wall thicknesses ranging from 0.097 to 0.216 inches! Pneumatic attachment. Save time and effort on the job with the TurboSlitter from Condux. Can be used with a standard drill. Pneumatic version: (min. 70 PSI) (max. 90 PSI)Telescoping clamp fits large or small drill housing.
Turbo Slitter - PNEUMATIC CONDUX 08010210
TurboSlitter Cordless Drill Attachment Condux 08010220
TurboSlitter-Cordless Drill Attachment CONDUX 08010220
The TurboSlitter™ from Condux can easily split HDPE pipe with wall thicknesses ranging from 0.097 to 0.216 inches! Available in two styles, pneumatic and cordless drill attachment. The cordless drill attachment quickly adjusts to fit almost any rechargeable drill, 14-volt and larger. Save time and effort on the job with the TurboSlitter from Condux.
Can be used with a standard drill
Lightweight shear head for easy one-hand control
TurboSlitter REPLACEMENT BLADES Condux 08010203
Replacement blades for the TurboSlitter™ from Condux, a cordless drill attachment that can easily split HDPE pipe with wall thicknesses ranging from 0.097 to 0.216 inches! The cordless drill attachment quickly adjusts to fit almost any rechargeable drill, 14-volt and larger. Save time and effort on the job with the TurboSlitter from Condux.
Condux TurboSlitter REPLACEMENT BLADES 08010203]
