Micro Optical Power Meter TEMPO OPM210
OTDR 1310/1550nm with OPM and Laser Source TEMPO 930XC-20C



Our Price: $252.00


Product Code: TEMPO-OPM210
Qty:

Description Technical Specs


Micro Optical Power Meters (OPM210 and OPM220) are available in standard and high-power versions for the Telco and MSO markets. Absolute and referenced power measurements ensure fast and accurate loss budget and insertion loss measurements. When placing tones on the fiber using a Tempo Communications source provides the optical power meter will definitively identify fiber optic cables.
Features
    • Standard and High Power Optical Power Meters
    • Measure Optical Power (dB, dBm & mW)
    • Accurate Insertion Loss Measurements
    • Tone and Probe Fiber Networks at 270Hz, 1kHz and 2kHz
    • Absolute or Referenced Optical Power Measurements
    • Integrated Visual Fault Locator
    • Integrated Flash Light
    • InGaAs detector for Maximum Sensitivity
    • Calibrated Wavelengths 850nm, 1300nm, 1310nm, 1490nm, 1550nm & 1625nm
    • Universal Bulkheads
    • Compatible with Singlemode and Multimode Networks
    • Auto Off or Continuous On Operation
    • AA Battery Operation
    • Supplied with Lanyard
