Nylon Cable Protector 1"-2 1/2" Condux 08042301
Condux Nylon Cable Protector is a Flanged, split tube to insert in duct end and protect cable from damage during installation. Can be left in place for permanent protection.
Conduit Size: 1'-2 1/2' (25-63mm)
Foam Carrier 1/2" Condux 08078200
Condux 08078200 Foam Carrier, lightweight carrier easily blow through duct. Best suited for start runs and operates with with multiple bends.
Specifications:
Duct Size: 1/2" (13 mm)
Max. OD: 0.50" (13 mm)
Foam Carrier 3/4" Condux 08078300
Condux 08078300 Foam Carrier, lightweight carrier easily blows through duct. Best suited for shorrt runs and operates with multiple bends.
Specifications:
- Duct Size: 3/4" (19 mm)
- Max. OD: 0.75" (19 mm)
Nylon Cable Protector 3"-6" Condux 08042300
Condux Nylon Cable Protector is a flanged, split tube to insert in duct end and protect cable from damage during installation. Can be left in place for permanent protection.
Conduit Size: 3"-6" (76-152mm)
Foam Carrier (Sponge) 1.75" Condux 08761441
Condux 08761441 Foam Carrier, is specially designed for spreading lubricant in duct prior
to fiber optic cable blowing/jetting.
Specifications:
- Carrier Size: 1.75" (44.5 mm)
- Duct Range (Inside) Diameter: 1.50" SDR 13.5, 11 (38 - 45 mm)
Foam Carrier (Sponge) 1.25" Condux 08761439
Condux 08761439 Foam Carrier, this foam carrier is specially designed for spreading lubricant in duct prior to fiber optic cable blowing/jetting.
Specifications:
- Carrier Size: 1.25" (31.8 mm)
- Duct Range (Inside) Diameter: 1" SDR 13.5, 11 (25 - 22 mm)
Foam Carrier (Sponge) 1.50" Condux 08761440
Condux 08761440 Foam Carrier, is specially designed for spreading lubricant in duct prior to fiber-optic
cable blowing/jetting.
Specification:
- Carrier Size: 1.50" (38.1 mm)
- Duct Range (Inside) Diameter: 1.25" (30-39 mm) SDR 13.5", 11
Venturi Air Plug Seal Disk Condux 08780223
Condux 08780223 Venturi Air Plug Seal Disk, blocks the the backward flow of air on the Condux Fiber-Optic Cable Blower while the user is conducting pressure tests and/or applying pre-lubricant in duct. The Seal disk is also used in conjunction with the Winch Line Blower when installing polyester pull tape.
Foam Carrier 4" Condux 08032600
Condux 08032600 Foam Carrier, lightweight carrier easily blow through duct. Best suited for start runs and operates with with multiple bends.
Specifications:
Duct Size: 4" (102 mm)
Max. OD: 4.00" (102 mm)
Foam Carrier 3" Condux 08032500
Condux 08032500 Foam Carrier, lightweight carrier easily blow through duct. Best suited for start runs and operates with with multiple bends.
Specifications:
Duct Size: 3" (76 mm)
Max. OD: 3.00" (76 mm)
Foam Carrier (Sponge) 2.00" Condux 08761442
Condux 08761442 Foam Carrier, is specially designed for spreading lubricant in duct prior
to fiber-optic cable blowing/jetting.
Specifications:
- Carrier Size: 2.00" (50.8 mm)
- Duct Range (Inside) Diameter: 2.00" SDR 13.5, 11 (46 - 52 mm)
Plastic Line Carrier 4" Condux 08030300
Condux 08030300 Line Carrier 4", is a fast and efficient plastic carrier for fishing with high-speed blowers even in out-of-round duct and will travel over any minor obstruction that might be inside the duct.
Specifications:
Duct Size: 4" (102mm)
Maximum OD: 4.06" (103mm)
Cable Seals 0.43" - 0.48" Condux 08761425
Condux 08761425 Cable Seals 0.43" - 0.48", replacement cable seals for Condux FIber-Optic Cable blowers are sold in
packs of four.These seals are compatible with the according cable venturi for the HD Blowers, Deluxe Lightweight Blower, and Mini Blower/Pusher.
Cable Seal for Gulfstream™ 400 Condux 08761435
Replacement Cable Seal for Fiber Optic Cable Blowers are sold in pack of 4.
Cable Diameter: 1.05-1.13
These seals work the the appropriate Cable Venturi for the following blower models:
HD Blower
Deluxe Lightweight Blower
Mini-Blower/Pusher
Cable Seal for Gulfstream™ 400 Condux 08761430
Replacement Cable Seal for Fiber Optic Cable Blowers are sold in pack of 4.
Cable Diameter: 0.074-0.079
These seals work the the appropriate Cable Venturi for the following blower models:
HD Blower
Deluxe Lightweight Blower
Mini-Blower/Pusher
Cable Seal for Gulfstream™ 400 Condux 08761427
Replacement Cable Seal for Fiber Optic Cable Blowers are sold in pack of 4.
Cable Diameter: 0.056-0.060
These seals work the the appropriate Cable Venturi for the following blower models:
HD Blower
Deluxe Lightweight Blower
Mini-Blower/Pusher
Cable Seal for Gulfstream™ 400 Condux 08761429
Replacement Cable Seal for Fiber Optic Cable Blowers are sold in pack of 4.
Cable Diameter: 0.068-0.073
These seals work the the appropriate Cable Venturi for the following blower models:
HD Blower
Deluxe Lightweight Blower
Mini-Blower/Pusher
Cable Seals 0.49" - 0.55" Condux 08761426
Condux 08761426 Cable Seals 0.49" - 0.55" , replacement cable seals for Condux Fiber-Optic Cable Blowers are sold in packs of four. These cable seals are compatible with the according cable venturi for the HD Blowers, Deluxe Lightweight Blower, and Mini-Blower/Pusher.
Cable Seal for Gulfstream™ 400 Condux 08761431
Replacement Cable Seal for Fiber Optic Cable Blowers are sold in pack of 4.
Cable Diameter: 0.080-0.085
These seals work the the appropriate Cable Venturi for the following blower models:
HD Blower
Deluxe Lightweight Blower
Mini-Blower/Pusher
Cable Seal for Gulfstream™ 400 Condux 08761432
Replacement Cable Seal for Fiber Optic Cable Blowers are sold in pack of 4.
Cable Diameter: 0.086-0.092
These seals work the the appropriate Cable Venturi for the following blower models:
HD Blower
Deluxe Lightweight Blower
Mini-Blower/Pusher
Cable Seal for Gulfstream™ 400 Condux 08761433
Replacement Cable Seal for Fiber Optic Cable Blowers are sold in pack of 4.
Cable Diameter: 0.093-0.097
These seals work the the appropriate Cable Venturi for the following blower models:
HD Blower
Deluxe Lightweight Blower
Mini-Blower/Pusher
Cable Seal for Gulfstream™ 400 Condux 08761434
Replacement Cable Seal for Fiber Optic Cable Blowers are sold in pack of 4.
Cable Diameter: 0.098-1.04
These seals work the the appropriate Cable Venturi for the following blower models:
HD Blower
Deluxe Lightweight Blower
Mini-Blower/Pusher
Cable Seal for Gulfstream™ 400 Condux 08761428
Replacement Cable Seal for Fiber Optic Cable Blowers are sold in pack of 4.
Cable Diameter: 0.061-0.067
These seals work the the appropriate Cable Venturi for the following blower models:
HD Blower
Deluxe Lightweight Blower
Mini-Blower/Pusher
Cable Seal for Gulfstream™ 400 Condux 08761424
Replacement Cable Seal for Fiber Optic Cable Blowers are sold in pack of 4.
Cable Diameter: 0.35-.42
These seals work the the appropriate Cable Venturi for the following blower models:
HD Blower
Deluxe Lightweight Blower
Mini-Blower/Pusher
SpeedBall Split Coupling Condux 08676844
CONDUX 08676844 Speed Ball Split Coupling
Hinged aluminum split coupling for temporarily joining all types on innerduct during a cable blowing process.
Inserts are sold separately
Duct Pack #2 - 3/4" Gulfstream 400 Condux 08780680
Each duct pack comes with:
- Duct Clamp - Part No. 08780682
- Duct Seal - Part No. 08780685
- Carrier - Part No. 08780690
- Foam Carrier - Part No. 08078300
- Cable Grip - Part No. 08643137
- Innerduct Eye - Part No. 08761840
Duct Pack #4 - 1.25" Gulfstream 400 Condux 08780392
Each duct pack comes with:
- Duct Clamp - Part No. 08780375
- Duct Seal - Part No. 08780051
- Carrier - Part No. 08761255
- Foam Carrier - Part No. 08761440
- Cable Grip - Part No. 08643149
- Innerduct Eye - Part No. 08761842
Duct Pack #5 - 1.5" Gulfstream 400 Condux 08780397
Each duct pack comes with:
- Duct Clamp - Part No. 08780404
- Duct Seal - Part No. 08780398
- Carrier - Part No. 08761260
- Foam Carrier - Part No. 08761441
- Cable Grip - Part No. 08643149
- Innerduct Eye - Part No. 08761844
Duct Pack #7 -20mm Gulfstream 400 Condux 08781120
Each duct pack comes with:
- Duct Clamp - Part No. 08780930
- Duct Seal - Part No. ???
- Carrier - Part No. 08761265
- Foam Carrier - Part No. 08761442
- Cable Grip - Part No. 08643155
- Innerduct Eye - Part No. 08761846
FIBER OPTIC CABLE EZ-EXIT GMP 90060
The fiber optic cable EZ-Exit tool eliminates damage to your fiber by easily guiding fiber optic cable past the sharp edges of a manhole chimney. The easy clamping feature allows the tool to be quickly installed in less than 30 seconds, reducing the total setup time of a fiber pull. Provides a rigid, low friction shoe that guides fiber over the sharp edges at the top and bottom of a manhole chimney while maintaining a bend diameter of 45” to accommodate up to some of the largest fiber cables.
Duct Pack #6 - 2" Gulfstream 400 Condux 08780930
Each duct pack comes with:
- Duct Clamp - Part No. 08780930
- Duct Seal - Part No. ???
- Carrier - Part No. 08761265
- Foam Carrier - Part No. 08761442
- Cable Grip - Part No. 08643155
- Innerduct Eye - Part No. 08761846
